Accessories Part 2
Type
Pole Ø
Fuses
Inputs
Outputs
Protection class
A
B
A
70 623
≥ 60 mm
1 Micro 6.3 A
2 · 3 × 2,5
9
1 · 3 × 1.5
9
IP 55
49
160
70 632
≥ 82 mm
1 Neozed 6 A
2 · 5 × 4
9
1 · 3 × 1.5
9
IP 55
59
160
B
71 084
≥ 110 mm
1 Micro 6.3 A
2 · 7 × 6
9
4 · 5 × 1.5
9
IP 54
75
250
70 629
≥ 110 mm
2 Neozed 6 A
2 · 5 × 10
9
2 · 4 × 2.5
9
IP 55
66
245
71 147
≥ 110 mm
2 Neozed 6 A
2 · 5 × 10
9
2 · 4 × 2.5
9
IP 54
72
265
C
70 647
≥ 120 mm
3 Neozed 6 A
2 · 5 × 16
9
2 · 5 × 2.5
9
IP 54
84
290
71 160
≥ 120 mm
3 Micro 10 A
1 · 5 × 4
9
4 · 5 × 1.0
9
IP 54
84
290
Connection boxes in accordance with DIN 43628/VDE 0660 · Part 505
Housings made of impact-resistant synthetic material
Connection boxes for bollards or luminaire poles
Connection box with control unit for power reduction or night-time reduction
with integrated DALI power supply for 9 standard DALI operating devices
Optionally adjustable to two operating modes:
Operating mode 1: Power reduction through network or control phase
Operating mode 2: Power reduction by way of virtual midnight calculation
Connection boxes in accordance with DIN 43628/VDE 0660 · Part 505
Housings made of impact-resistant synthetic material
Connection box with control unit for power reduction with DALI interface
Type
Pole Ø
Fuses
Inputs
Outputs
Protection class
A
B
C
71 143
≥ 120 mm
2 Neozed 6 A
2 · 5 × 16
9
2 · 5 × 1.5
9
IP 54
84
290
Connection box with overvoltage protection for installation in luminaire poles
Type
Pole Ø
Fuses
Inputs
Outputs
Protection class
A
B
B
71 087
≥ 110 mm
1 Micro 6.3 A
2 · 7 × 6
9
2 · 5 × 1.5
9
IP 54
75
250
C
70 695
≥ 120 mm
2 Neozed 6 A
2 · 5 × 16
9
2 · 4 × 2.5
9
IP 54
84
290
71 087 Connection box with overvoltage protection in compliance with EN 61643-11
for LED luminaires with 1 –10 V or DALI interface
70 695 Connection box with overvoltage protection in accordance with EN 61643-11
Connection boxes in accordance with DIN 43628/VDE 0660 · Part 505
Housings made of impact-resistant synthetic material
Connection box with DALI-USB interface for installation in luminaire poles
Type
Pole Ø
Fuses
Inputs
Outputs
Protection class
A
B
C
71 089
≥ 120 mm
1 Micro 5 A
3 · 5 × 16
9
2 · 5 × 1.5
9
IP 54
84
290
Connection box with DALI USB interface for the setup and power supply (250 mA) of DALI operating devices and
control components on a DALI line with max. 64 operating devices and additional control components.
The free DALI Cockpit software can be downloaded from our website for configuration purposes – see Page 412.
Connection boxes in accordance with DIN 43628/VDE 0660 · Part 505
Housings made of impact-resistant synthetic material
Connection box with Bluetooth DALI gateway for installation in luminaire poles
Type
Pole Ø
Fuses
Inputs
Outputs Protection class
A
B
B
71 085
≥ 110 mm
1 Micro 6.3 A
2 · 7 × 6
9
2 · 5 × 1.5
9
IP 54
75
250
Connection box with Bluetooth DALI gateway for the commissioning and power supply (250 mA)
of DALI operating devices and control components on a DALI line with max. 64 operating devices
and additional control components.
Setup and configuration are carried out via the free BEGA Tool app – see Page 413.
Connection boxes in accordance with DIN 43628/VDE 0660 · Part 505
Housings made of impact-resistant synthetic material
Connection boxes and accessories for BEGA pole-top luminaires,
light building elements and bollards
Connection boxes are used to connect bollards, light building elements and pole-top luminaires.
In addition to serving as the electrical transfer point from the underground cable to the luminaire
supply line and as the electrical fuse protection of the luminaires, they can take on various additional
functions through integrated components. You can find the complete technical data in the data sheets
on our website. The installation and operation of these connection boxes are subject to national safety
regulations.
Connection box with residual current automatic cutout for installation in bollard tubes and luminaire poles
Type
Pole Ø
Residual current device/MCB
Inputs
Outputs
Protec. class
A
B
D
71 306
≥ 120 mm
30 mA / C 32 A 4-pole 1 · 5 × 10
9
1 · 5 × 6
9
IP 54
100
385
Connection box with residual current automatic cutout and surge voltage protector for connection of the BEGA charging
unit integrated into the bollard tubes and luminaire poles.
Housings made of impact-resistant synthetic material
