Anchorage units for bollards and luminaire poles with base plate
Hot-dip galvanised welded construction made of steel
Thread inserts and mounting screws made of stainless steel
Screw connection
A
B
C
D
70 894 Anchorage unit
3 × 120° M6
95
400
345
70
70 895 Anchorage unit
3 × 120° M8
135
400
335
100
70 896 Anchorage unit
3 × 120° M8
165
500
345
132
Anchorage units for light building elements
Hot-dip galvanised welded construction made of steel
Thread inserts and mounting screws made of stainless steel
A
B
C
D
71 242 Anchorage unit
—
715
330
90
71 136 Anchorage unit
155
800
455
108
71 137 Anchorage unit
210
800
455
108
71 135 Anchorage unit
290
1000
455
133
71 207 Anchorage unit
—
1140
415
90
71 138 Anchorage unit
390
1300
950
220
71 192 Anchorage unit
100 × 40
800
465
80 × 40
71 140 Anchorage unit
150 × 90
800
425
120 × 60
71 091 Anchorage unit
310 × 210
1000
530
133
71 139 Anchorage unit
395 ×175
1000
455
133
Anchorage units for rectangular bollards
Hot-dip galvanised welded construction made of steel
Thread inserts and mounting screws made of stainless steel
Screw connection
A
B
C
D
71 178 Anchorage unit
2 × 180° M8
155 ×106
400
290
125
71 890 Anchorage unit
2 × 180° M8
250 × 85
400
290
220
Anchorage units for luminaire poles with base plate
Hot-dip galvanised welded construction made of steel
Thread inserts and mounting screws made of stainless steel
Screw connection
A
B
C
D
70 897 Anchorage unit
4 × 90° M10
235
600
455
200
70 898 Anchorage unit
4 × 90° M12
310
800
450
265
70 899 Anchorage unit
4 × 90° M16
335
800
450
283
71 219 Anchorage unit
4 × 90° M16
410
1000
440
353
Accessories Part 2
Anchorage units for bicycle stands
Hot-dip galvanised welded construction made of steel
Thread inserts and mounting screws made of stainless steel
Screw connection
A
B
C
D
• 71 351 Anchorage unit
2 × 180° M8 185 ×105
500
200
150
431
