Accessories for BEGA floodlights with G ½ threaded connection
Pole-top cross beam for 3 floodlights
with G ½ threaded connection
For the permanent installation of floodlights
with a G ½ threaded connection on poles Ø 76 mm
Please check whether the length of the cross beams on the
floodlights can be adjusted locally for the desired illumination.
Dimensions and information about the swivel
ranges can be found in the instructions
for use for the floodlights.
Protection class IP 55 · Cast aluminium
For pole top
A
71 261 Pole-top cross beam
Ø 76
600
71 248 Pole-top cross beam
Ø 76
820
Accessory colour · BEGA Unidure ®
Graphite – article number
Silver
– article number + A
70 252 Stainless steel
70 204 Colour graphite
Pole caps with G ½ threaded connection
For the permanent installation of floodlights with a G ½
threaded connection on poles
Cast aluminium
For pole top
Insert depth
70 214 Pole cap
Ø 48
50
70 248 Pole cap
Ø 60
80
70 249 Pole cap
Ø 76
95
70 229 Pole cap
Ø 82
100
Pole adapter with G ½ threaded connection
For the permanent installation of floodlights with a G ½
threaded connection on poles or existing pipes.
Cast aluminium
Recessed opening Ø 30 mm
71 042 Pole adapter
Side-mounted pole-top cross beam
with G ½ threaded connection
For the permanent installation of floodlights
with a G ½ threaded connection on poles Ø ≥60 mm
or on wall surfaces
Cast aluminium
Overhang 190 mm
70 379 Side-mounted pole-top cross beam
Mounting box for foundations or anchorage units
with G ½ threaded connection
For the permanent installation of floodlights with a G ½ threaded
connection on a foundation or separately ordered anchorage unit
Protection class IP 65 · Cast aluminium
2 screw cable glands for connecting cable Ø 9 – 15 mm
Ø
H
70 221 Mounting box
130
80
70 894 Anchorage unit for 70 221
Round mounting boxes with G ½ threaded connection
For the permanent installation of floodlights with a G ½
threaded connection on columns, walls or ceilings
Protection class IP 65 · Cast aluminium
2 cable entries
Ø
H
70 217
Round mounting box
110
45
70 294
Round mounting box
130
50
70 284
Round mounting box
150
55
Accessories for BEGA floodlights with G ½ threaded connection
There are a large number of different installation situations for floodlights.
For most applications, we can offer devices ready for connection. For all other situations, you will find accessories
here that can be individually bolted to BEGA floodlights with G ½ threaded connection in accordance with ISO 228.
BEGA floodlights with G ½ threaded connection ordered in combination with accessories 70 252, 70 283, 70 280,
70 889 and 70 204 on Page 427 are supplied factory-assembled and ready for connection.
You will find the data sheets and instructions for use for each accessory on our website.
