215
305
65
86
70
61
DALI system components
DALI operating devices
DALI operating devices for
• RGB in-ground luminaires 24 V DC
for max. 15 luminaires 33 291 · 88 897 or
6 luminaires 33 292 · 88 898 or 2 luminaires 33 293 · 88 899
• RGBW swimming pool luminaires 24 V DC
for max. 5 luminaires 99 815
Protection class IP 65 · Safety class I
Cast aluminium and aluminium
Additive colour mixing can be performed using any commercially available DALI colour light
control (DT 8, RGBW, xy) system. If there is no internal DALI power supply in the
DALI colour light control system, DALI power supply 70 866 can be used.
A separate power supply unit is required for operation.
Additional information on BEGA power supply units can be found on Page 420.
71 018
For RGB recessed luminaires 24 V DC
71 019
For RGBW swimming pool luminaires 24 V DC
KNX-DALI-2 Gateway for DIN rail mounting
IPAS KNX/DALI-2 gateway for the integration of up to 64 DALI operating devices in one
KNX system Parametrisation of 16 DALI groups, 16 DALI lighting scenarios and 16 sequences
via application program in the ETS software.
The DALI colour light control of tunable white and RGBW luminaires (DT 8, RGBWAF, xy)
can also be achieved in this way.
KNX teaching button for switching from normal operation to addressing operation and
three further buttons for device setting and configuration on the front.
Also suitable for operating single emergency lighting battery luminaires with DALI control
in accordance with DIN EN 62386-202.
71 065
IPAS KNX-DALI-2 gateway
416
