Part 2
71 262 Air Connector in a housing for wall mounting
Protection class IP 66
Glass-fibre reinforced synthetic material · 2 cable entries
Integrated DALI power supply, 100 mA
For controlling up to 20 DALI operating devices
Integrated mobile radio connection via narrowband IoT
The illustration shows parts of the black housing
transparently for better clarification of the system.
71 297 Air Connector in a housing for installation on a pole
Protection class IP 65 · Cast aluminium · Synthetic material
6 m connecting cable with free cable ends
DALI power supply integrated, 100 mA
For controlling up to 20 DALI operating devices
Integrated mobile radio connection via narrowband IoT
Luminaire colour · BEGA Unidure®
Graphite – article number
Silver
– article number + A
The illustration shows parts of the black housing
transparently for better clarification of the system.
71 298 Air Connector for installation in a protected connection compartment
Protection class IP 20
DALI power supply integrated, 100 mA
For controlling up to 20 DALI operating devices
Integrated mobile radio connection via narrowband IoT
71 209 DALI connector for DIN rail mounting
Integrated DALI power supply, 250 mA
For controlling up to 64 DALI operating devices
and 64 control devices compliant with DALI2 standard
The technical data for all BEGA Connect components can be found in the data sheets on our website.
Air Connector for installation in a protected connection compartment
Air Connector in a housing for wall mounting
Air Connector in a housing for installation on a pole
DALI connector for DIN rail mounting
• 71 210 Zhaga Air Connector for direct installation on a luminaire
Protection class IP 66
Synthetic material · Installation via Zhaga Book 18 Ed 3.0 interface
Power supply via DALI-2 power supply unit (DiiA 150) in the luminaire
For controlling an individual luminaire
Zhaga Air Connector for direct installation on a luminaire
• 71 328 DALI-2 Zhaga motion and light sensor
Protection class IP 66
Synthetic material · Installation via downward-directed Zhaga Book 18 Ed 3.0 interface
The passive infrared motion and light sensor reacts to thermal radiation, switching to account
for the environmental brightness when people or animals move in its vicinity.
In combination with Zhaga Air Connector, ideally suited for street illumination with mounting
heights between 4000 - 8000 mm
Power supply via DALI-2 power supply unit (DiiA 150) in the luminaire
DALI-2 Zhaga motion and light sensor for direct installation on a luminaire
• New in the range
Zhaga Air Connector for direct installation on a luminaire
