For planning and installation, please refer to the technical planning data. The user instructions and data sheets available
on our website offer all the latest information about LED service life, luminous flux and max. ambient temperatures.
BEGA system pendant luminaires · Downlights
Wide beam or very wide beam light distribution
Luminaire housing made of cast aluminium
Luminaire housing, rod suspension and installation components available with a choice of 2 finishes
Cable pendant in luminaire colour · Special lengths on request
BEGA Hybrid Optics®
Reflector surface made of pure aluminium · Safety glass · Chrome trim ring
We can also deliver the chrome trim rings in the exterior colour on request.
on/off or DALI controllable power supply units · BEGA Thermal Management ®
When used with canopy types AS and CS, the luminaires are also controllable using BEGA Smart.
Colour rendering index (CRI) > 90
Colour temperature: 3000 K – article number + K3
20-year availability guarantee for replacement parts and LED modules
An overview of the prices for the various installation components can be found on Page 381. Installation components
are accessories for BEGA system pendant luminaires and must be ordered together with the pendant luminaires.
Colour velvet black · Wide beam light distribution
Velvet black
LED
Controllable
β
A
B
L
Type A
Type AS
Type B
Type BS
Type C
Type CS
Type D
51 159.5 5.6 W
435 lm
on/off
27°
90
90
2000
13 228 13 281 13 231
—
13 234 13 284 13 221
51 162.5 13.7 W
1610 lm
on/off
36°
120
115
2000
13 239
—
13 258
—
13 260
—
13 217
51 164.5 19.5 W
2265 lm
DALI
32°
135
125
3000
13 251 13 270 13 258 13 268 13 260 13 274 13 225
51 166.5 27.6 W
3535 lm
DALI
30°
180
150
3000
13 256 13 270 13 258 13 268 13 260 13 274 13 225
BEGA system pendant luminaires
Installation components
Colour velvet white · Wide beam light distribution
Velvet white
LED
Controllable
β
A
B
L
Type A
Type AS
Type B
Type BS
Type C
Type CS
Type D
51 159.1 5.6 W
435 lm
on/off
27°
90
90
2000
13229
13 282 13 232
—
13 235 13 285 13 220
51 162.1 13.7 W
1610 lm
on/off
36°
120
115
2000
13 245
—
13 259
—
13 261
—
13 226
51 164.1 19.5 W
2265 lm
DALI
32°
135
125
3000
13 255 13 276 13 259 13 269 13 261 13 275 13 224
51 166.1 27.6 W
3535 lm
DALI
30°
180
150
3000
13 257 13 276 13 259 13 269 13 261 13 275 13 224
Colour velvet black · Very wide beam light distribution
Velvet black
LED
Controllable
β
A
B
L
Type A
Type AS
Type B
Type BS
Type C
Type CS
Type D
51 167.5 5.6 W
430 lm
on/off
54°
90
90
2000
13 228 13 281 13 231
—
13 234 13 284 13 221
51 171.5 13.7 W
1590 lm
on/off
74°
120
115
2000
13 239
—
13 258
—
13 260
—
13 217
51 173.5 19.5 W
2185 lm
DALI
61°
135
125
3000
13 251 13 270 13 258 13 268 13 260 13 274 13 225
51 175.5 27.6 W
3425 lm
DALI
59°
180
150
3000
13 256 13 270 13 258 13 268 13 260 13 274 13 225
Colour velvet white · Very wide beam light distribution
Velvet white
LED
Controllable
β
A
B
L
Type A
Type AS
Type B
Type BS
Type C
Type CS
Type D
51 167.1 5.6 W
430 lm
on/off
54°
90
90
2000
13 229 13 282 13 232
—
13 235 13 285 13 220
51 171.1 13.7 W
1590 lm
on/off
74°
120
115
2000
13 245
—
13 259
—
13 261
—
13 226
51 173.1 19.5 W
2185 lm
DALI
61°
135
125
3000
13 255 13 276 13 259 13 269 13 261 13 275 13 224
51 175.1 27.6 W
3425 lm
DALI
59°
180
150
3000
13 257 13 276 13 259 13 269 13 261 13 275 13 224
Indoor luminaires Part 3
Supplement
Page 47
