H
h
E
d
Ø
H
h
d
Ø
D
Group 32
Cylindrical aluminium luminaire poles
Pole
H
d
h
Ø
E
kg
Connection box
70 740
2000
60
90
82
500
7.0
A
70 741
2500
60
90
82
500
9.0
A
70 752
3000
60
90
82
500
9.0
A
70 906
3500
76
130
135
800
19.5
B · C
70 739
3500
76
80
135
800
21.5
B · C
70 742
4000
76
130
135
800
22.5
B · C
70 738
4000
76
80
135
800
22.5
B · C
70 737
4000
76
100
170
800
32.5
B · C
70 743
4500
76
130
135
800
26.5
B · C
70 736
4500
76
80
135
800
26.5
B · C
70 744
5000
76
130
135
800
30.0
B · C
70 727
5000
76
80
135
800
30.5
B · C
70 748
5000
76
100
170
1000
40.0
B · C
70 909
3000
82
120
100
500
13.0
A
Cylindrical aluminium luminaire poles with anchorage section and stepped pole top
in accordance with DIN EN 40
with painted finish
These luminaire poles with door are equipped with a C-clamp to accommodate a connection box
and a PE conductor connection. Matching connection boxes for each application are listed in the
table. For more information about BEGA connection boxes, see Page 433.
We supply all luminaire poles in the colour of the luminaires ordered. If no colour is specified, we
deliver the poles in the colour graphite. All standard colours feature our BEGA Unidure® coating
technology and meet the highest global standards of weathering and light stability.
On request, poles can also be supplied in RAL textures and DB colours at the catalogue price.
20-year availability guarantee for replacements
Cylindrical aluminium luminaire poles with base plate and stepped pole top
in accordance with DIN EN 40
with painted finish
We offer two mounting systems for mounting the luminaire poles with base plate to a foundation
or anchorage unit. A description of the two systems can be found on Page 290. Each pole group
is assigned the corresponding mounting system.
These luminaire poles with door are equipped with a C-clamp to accommodate a connection box
and a PE conductor connection. Matching connection boxes for each application are listed in the
table. For more information about BEGA connection boxes, see Page 433.
We supply all luminaire poles in the colour of the luminaires ordered. If no colour is specified, we
deliver the poles in the colour graphite. All standard colours feature our BEGA Unidure® coating
technology and meet the highest global standards of weathering and light stability.
On request, poles can also be supplied in RAL textures and DB colours at the catalogue price.
20-year availability guarantee for replacements
Group 12
Cylindrical aluminium luminaire poles · Mounting system 1
Pole
H
d
h
Ø
D
kg
Connection box
Anch. unit
70 907
2000
60
90
82
220
10.0
A
70 896
70 908
2000
60
100
100
220
11.0
A
70 896
70 722
2500
60
90
82
220
12.0
A
70 896
70 723
3000
60
90
82
220
14.0
A
70 896
70 930
3000
60
45
120
300
17.5
B · C
70 897
Cylindrical aluminium luminaire poles · Mounting system 2
Pole
H
d
h
Ø
D
kg
Connection box
Anch. unit
70 732
3500
76
130
135
340
21.5
B · C
70 899
70 729
3500
76
80
135
340
21.5
B · C
70 899
70 733
4000
76
130
135
340
31.5
B · C
70 899
70 728
4000
76
80
135
340
24.5
B · C
70 899
70 731
4000
76
100
170
360
48.5
B · C
70 899
70 734
5000
76
100
170
360
55.0
B · C
70 899
H = Pole height, without anchorage section
d = Pole top diameter
h = Stepped pole top height
Ø = Pole base diameter
D = Diameter of base plate
E = Anchorage section
kg = Total weight
Group 32
Group 12
Accessories Part 2
291
