D
B
C
A
D
B
C
A
B
A
C
A
B
LED lamp included
Socket
Connection
A
B
C
D
Anch. unit
84 073 1 × 7.0 W
255 lm
E 27
Terminals 3 × 4
9
200
990
270
140
70 895
LED lamp included
Socket
Connection
A
B
C
D
Anch. unit
84 075 1 × 7.0 W
80 lm
E 27
Terminals 5 × 2.5
9
160
1000
210
160
70 895
Bollards
Protection class IP 55
Cast aluminium · Cylindrical lens made of crystal glass
We supply the E 27 socket luminaires complete with corresponding LED lamps.
Colour temperature: 3000 K – article number + K3
Technical data for BEGA LED lamps can be found on Page 418.
These BEGA bollards are equipped with an adjustable mounting system.
It can either be bolted onto a foundation provided by the customer, or onto a
BEGA anchorage unit. Anchorage units are accessories and need to be ordered
separately.
For more information about BEGA anchorage units, see Page 431.
Luminaire colour · BEGA Unidure®
Graphite – article number
Bronze – article number + B
20-year availability guarantee for replacements
LED lamp included
Socket
Connection
A
B
Anch. unit
84 080 1 × 8.0 W
750 lm
E 27
Terminals 3 × 4
9
140
810
70 894
88 632 1 × 12.0 W
900 lm
E 27
70 632
165
990
70 895
Garden luminaire
Shielded light
Protection class IP 64
Cast aluminium · Crystal bubble glass
We supply the E 27 socket luminaires complete with corresponding LED lamps.
Colour temperature: 3000 K – article number + K3
Technical data for BEGA LED lamps can be found on Page 418.
This BEGA garden luminaire is equipped with an adjustable mounting system.
It can either be bolted onto a foundation provided by the customer, or onto a
BEGA anchorage unit. Anchorage units are accessories and need to be ordered
separately.
For more information about BEGA anchorage units, see Page 431.
Luminaire colour · BEGA Unidure®
Graphite – article number
Bronze – article number + B
20-year availability guarantee for replacements
Garden luminaire
Protection class IP 64
Cast aluminium · Hand-blown opal glass with thread
We supply the E 27 socket luminaires complete with corresponding LED lamps.
Colour temperature: 3000 K – article number + K3
Technical data for BEGA LED lamps can be found on Page 418.
This BEGA garden luminaire is equipped with an adjustable mounting system.
It can either be bolted onto a foundation provided by the customer, or onto a
BEGA anchorage unit. Anchorage units are accessories and need to be ordered
separately.
For more information about BEGA anchorage units, see Page 431.
Luminaire colour · BEGA Unidure®
Graphite – article number
Bronze – article number + B
20-year availability guarantee for replacements
Please refer to the technical planning data for planning and installation. The current values for LED service life,
luminous flux, maximum ambient temperature and information about the use of BEGA Thermal Management ®
are readily available in the instructions for use and data sheets on our website.
Bollard
Shielded light
Protection class IP 65
Cast aluminium · Borosilicate glass
Reflector made of pure anodised aluminium
on/off power supply units · BEGA Thermal Management ®
This BEGA bollard is equipped with an alignable mounting system.
It can either be bolted onto a foundation provided by the customer or onto a
BEGA anchorage unit. Anchorage units are accessories and need to be ordered
separately.
For more information about BEGA anchorage units, see Page 431.
LED colour temperature: 3000 K – article number + K3
Luminaire colour · BEGA Unidure®
Graphite – article number
Bronze – article number + B
20-year availability guarantee for replacement parts and LED modules
LED
Controllable
Connection box
A
B
C
Anch. unit
77 762 13.6 W
425 lm
on/off
70 632
165
860
220
70 896
Outdoor luminaires Part 2
Supplement
Page 41
Illumination
diagrams
Supplement
Page 41
Illumination
diagrams
285
