Pole-top luminaires and side-mounted pole-top luminaires for bracket poles
Asymmetrical flat beam light distribution
Protection class IP 66 · Safety class II
Cast aluminium · Anti-glare safety glass
Reflector made of pure anodised aluminium · BEGA Constant Optics ®
Attack angle adjustable to 0° or 15°
Luminaires can be opened without tools
BEGA Ultimate Driver ® · DALI controllable · BEGA Thermal Management ®
These luminaires emit no light into the upper half-space of the luminaires.
Power reduction accessories for luminaires with a DALI interface can be found on Page 417.
If requested, we can also supply these luminaires in a double version.
In the table, we recommend BEGA luminaire poles that match the finish and colour, as well as the design
and statics of the pole-top luminaires in this series. The complete overview and technical data for all
BEGA luminaire poles can be found on Pages 290 to 299.
You can find BEGA anchorage units and connection boxes on Pages 431 to 433.
LED colour temperature: 3000 K – article number + K3 or 4000 K – article number + K4
Luminaire colour · BEGA Unidure ®
Graphite – article number
Silver
– article number + A
20-year availability guarantee for replacement parts and LED modules
Pole-top luminaires · Asymmetrical flat beam light distribution
Luminaire poles
LED
Controllable
A
B
C
For pole heights
Top
Groups
77 825 13.5 W
1895 lm
DALI
260
55
520
3500 – 5000
Ø 76
34 · 14 · 17 · 33 · 13
77 853 25.5 W
3755 lm
DALI
260
55
520
5000 – 7000
Ø 76
72 · 14 · 17 · 33 · 13
77 858 34.0 W
4645 lm
DALI
260
55
520
5000 – 8000
Ø 76
72 · 14 · 17 · 33 · 13
Asymmetrical flat beam
Pole-top luminaires · Pole-top luminaires with outrigger arm · Side-mounted pole-top luminaires for bracket poles
* Also available for Ø 60 mm pole top on request.
The luminaires in our Dark Sky range
direct their light onto the surface to
be illuminated with high efficiency,
while emitting no light into the upper
half-space of the luminaire.
bega.com/darksky
Supplement
Page 38
Illumination
diagrams
256
