DarkSky
C
B
C
A
Asymmetrical
Asymmetrical flat beam
Pole-top luminaires optionally with Zhaga interfaces
and side-mounted pole-top luminaires for bracket poles
Asymmetrical or asymmetrical flat beam light distribution
Protection class IP 66 · Safety class II
Cast aluminium · Anti-glare safety glass
Reflector surface made of pure aluminium · BEGA Constant Optics ®
BEGA Ultimate Driver ® · DALI controllable · BEGA Thermal Management ®
These luminaires emit no light into the upper half-space of the luminaires.
Power reduction accessories for luminaires with a DALI interface can be found on Page 417.
Some luminaires come equipped with two Zhaga interfaces as per Zhaga Book 18 Ed. 3.0. Zhaga modules are not included in the delivery.
In the table, we recommend BEGA luminaire poles that match the finish and colour, as well as the design and statics of the pole-top luminaires
in this series. The complete overview and technical data for all BEGA luminaire poles can be found on Pages 290 to 299.
You can find BEGA anchorage units and connection boxes on Pages 431 to 433.
LED colour temperature: 3000 K – article number + K3 or 4000 K – article number + K4
Luminaires with BEGA BugSaver ® technology can be switched from warm white light with a colour temperature of 3000 K to light with
highly reduced blue light portion to protect nocturnal insects. This phosphor-converted amber has a colour temperature of around 1800 K
and is considered to be particularly insect-friendly. Our control devices can be used to achieve additional power reduction, see Page 417.
Luminaire colour · BEGA Unidure ® · Graphite
20-year availability guarantee for replacement parts and LED modules
Pole-top luminaires · Asymmetrical light distribution
Luminaire poles
LED
Controllable
A
B
C
For pole heights
Top
Groups
84 581 18.2 W
2335 lm
DALI
Single
240
60
450
4000 – 6000
Ø 76
34 · 14 · 17 · 33 · 13
84 582 33.5 W
4670 lm
DALI
Single
240
60
450
5000 – 8000
Ø 76
34 · 72 · 17 · 33 · 13
84 585 51.0 W
6700 lm
DALI
Single
320
75
520
7000 – 9000
Ø 76
34 · 72
84 586 67.0 W
9335 lm
DALI
Single
320
75
520
7000 – 9000
Ø 76
34 · 72
84 583 36.4 W
4670 lm
DALI
Double
240
60
805
4000 – 6000
Ø 76
34 · 14 · 17 · 33 · 13
84 584 67.0 W
9335 lm
DALI
Double
240
60
805
5000 – 8000
Ø 76
34 · 72 · 17 · 33 · 13
84 587 102.0 W
13 995 lm
DALI
Double
320
75
935
7000 – 9000
Ø 76
34 · 72
84 588 134.0 W
18 670 lm
DALI
Double
320
75
935
7000 – 9000
Ø 76
34 · 72
84 653 34.5 W
4670 lm
Zhaga
Single
240
60
550
5000 – 8000
Ø 76
34 · 72 · 17 · 33 · 13
84 655 69.0 W
9335 lm
Zhaga
Single
320
75
615
7000 – 9000
Ø 76
34 · 72
Pole-top luminaires · Asymmetrical flat beam light distribution
Luminaire poles
LED
Controllable
A
B
C
For pole heights
Top
Groups
84 589 18.2 W
2345 lm
DALI
Single
240
60
450
4000 – 6000
Ø 76
34 · 14 · 17 · 33 · 13
84 590 33.5 W
4550 lm
DALI
Single
240
60
450
5000 – 8000
Ø 76
34 · 72 · 17 · 33 · 13
84 593 51.2 W
6900 lm
DALI
Single
320
75
520
7000 – 9000
Ø 76
34 · 72
84 594 67.0 W
9160 lm
DALI
Single
320
75
520
7000 – 9000
Ø 76
34 · 72
84 591 36.4 W
4690 lm
DALI
Double
240
60
805
4000 – 6000
Ø 76
34 · 14 · 17 · 33 · 13
84 592 67.0 W
9110 lm
DALI
Double
240
60
805
5000 – 8000
Ø 76
34 · 72 · 17 · 33 · 13
84 595 102.4 W
13 800 lm
DALI
Double
320
75
935
7000 – 9000
Ø 76
34 · 72
84 596 134.0 W
18 320 lm
DALI
Double
320
75
935
7000 – 9000
Ø 76
34 · 72
84 657 34.5 W
4550 lm
Zhaga
Single
240
60
550
5000 – 8000
Ø 76
34 · 72 · 17 · 33 · 13
84 659 69.0 W
9160 lm
Zhaga
Single
320
75
615
7000 – 9000
Ø 76
34 · 72
Luminaires with two
separate Zhaga interfaces
Zhaga motion sensors
see Page 411
Pole-top luminaires · Pole-top luminaires with outrigger arm · Side-mounted pole-top luminaires for bracket poles
Supplement
Page 37
Illumination
diagrams
254
