Pole-top luminaires optionally with Zhaga interface
Symmetrical or asymmetrical flat beam light distribution
Protection class IP 65 · Safety class II
Cast aluminium · Synthetic cover with optical texture
Reflector surface made of pure aluminium
BEGA Thermal Management ®
These luminaires emit no light into the upper half-space of the luminaires.
The luminaires 85 011 and 85 012 are DALI controllable. Power reduction accessories
for luminaires with a DALI interface can be found on Page 417.
The luminaires 85 013 and 85 014 come equipped with one Zhaga interface as per Zhaga Book 18 Ed. 3.0.
In the table, we recommend BEGA luminaire poles that match the finish and colour, as well as the design
and statics of the pole-top luminaires in this series. The complete overview and technical data for all
BEGA luminaire poles can be found on Pages 290 to 299.
You can find BEGA anchorage units and connection boxes on Pages 431 to 433.
LED colour temperature: 3000 K – article number + K3 or 4000 K – article number + K4
Luminaires with BEGA BugSaver ® technology can be switched from warm white light with a colour
temperature of 3000 K to light with highly reduced blue light portion to protect nocturnal insects.
This phosphor-converted amber has a colour temperature of around 1800 K and is considered to be
particularly insect-friendly. Our control devices can be used to achieve additional power reduction,
see Page 417.
Luminaire colour · BEGA Unidure ®
Graphite – article number
Silver
– article number + A
20-year availability guarantee for replacement parts and LED modules
Symmetrical light distribution
Luminaire poles
LED
Controllable
A
B
For pole heights
Top
Groups
85 011 27.0 W
3270 lm
DALI
550
160
4000 – 6000
Ø 76
34 · 14 · 17 · 33 · 13
85 013 28.0 W
3270 lm
Zhaga
550
160
4000 – 6000
Ø 76
34 · 14 · 17 · 33 · 13
Asymmetrical flat beam light distribution
Luminaire poles
LED
Controllable
A
B
For pole heights
Top
Groups
85 012 27.0 W
2660 lm
DALI
550
160
4000 – 6000
Ø 76
34 · 14 · 17 · 33 · 13
85 014 28.0 W
2660 lm
Zhaga
550
160
4000 – 6000
Ø 76
34 · 14 · 17 · 33 · 13
Symmetrical light distribution · BEGA BugSaver®
Luminaire poles
LED
Controllable
A
B
For pole heights
Top
Groups
85 070 28.5 W
2950 lm
DALI DT8 TW
550
160
4000 – 6000
Ø 76
34 · 14 · 17 · 33 · 13
Asymmetrical flat beam light distribution · BEGA BugSaver®
Luminaire poles
LED
Controllable
A
B
For pole heights
Top
Groups
85 071 28.5 W
2415 lm
DALI DT8 TW
550
160
4000 – 6000
Ø 76
34 · 14 · 17 · 33 · 13
Asymmetrical-
flat beam
Symmetrical
We have developed luminaires with
BEGA BugSaver®-technology for
efficient illumination in urban and
natural surroundings. This system
allows a switch-over to amber light,
which is far less attractive to insects.
bega.com/bugsaver
The luminaires of our Dark Sky range
direct their light onto the surface to be
illuminated with high efficiency, while
emitting less than 1 % of their luminaire
luminous flux into the upper half-space
of the luminaire.
bega.com/darksky
Please refer to the technical planning data for planning and installation. The current values for LED service life, luminous flux,
maximum ambient temperature and information about the use of BEGA Thermal Management ® are readily available in the
instructions for use and data sheets on our website.
Outdoor luminaires Part 2
A
B
Supplement
Page 34
Illumination
diagrams
247
