70 833
Light building elements
Asymmetrical and asymmetrical flat beam light distribution
Protection class IP 65 · Cast aluminium and aluminium · Safety glass
Reflector made of pure anodised aluminium · BEGA Constant Optics®
BEGA Ultimate Driver ® · DALI controllable · BEGA Thermal Management ®
Connection box 71 084
These luminaires emit less than 1 % of the light into the upper half-space of the luminaires.
Power reduction accessories for luminaires with a DALI interface can be found on Page 417.
The technical data for the connection boxes can be found on Page 433.
BEGA light building elements of this series are secured in the ground using an anchorage unit
or bolted onto a construction side foundation via a screw-on base.
Please order anchorage units and screw-on bases separately as accessories. Additional information
about BEGA anchorage units and screw-on bases can be found on Pages 412 to 417.
Luminaires with BEGA BugSaver ® technology can be switched from warm white light with a colour
temperature of 3000 K to light with highly reduced blue light portion to protect nocturnal insects.
This phosphor-converted amber has a colour temperature of around 1800 K and is considered to be
particularly insect-friendly. Our control devices can be used to achieve additional power reduction,
see Page 417.
LED colour temperature: 3000 K – article number + K3 or 4000 K – article number + K4
Luminaire colour · BEGA Unidure®
Graphite – article number
Silver
– article number + A
20-year availability guarantee for replacement parts and LED modules
Asymmetrical flat beam light distribution · Single
Anch. unit
Screw-on base
LED
Controllable
A
B
C
D
84 273 18.0 W
1875 lm
DALI
285 × 240
65
3500
800
71 140
70 833
99 072 18.0 W
1875 lm
DALI
315 × 240
105
4500
800
71 140
70 833
Asymmetrical flat beam light distribution · Double
Anch. unit
Screw-on base
LED
Controllable
A
B
C
D
84 275 36.0 W
3760 lm
DALI
460 × 240
65
3500
800
71 140
70 833
99 076 36.0 W
3760 lm
DALI
520 × 240
105
4500
800
71 140
70 833
Asymmetrical light distribution · Single
Anch. unit
Screw-on base
LED
Controllable
A
B
C
D
84 274 20.0 W
2510 lm
DALI
285 × 240
65
3500
800
71 140
70 833
84 240 20.0 W
2510 lm
DALI
315 × 240
105
4500
800
71 140
70 833
Asymmetrical light distribution · Double
Anch. unit
Screw-on base
LED
Controllable
A
B
C
D
84 276 38.3 W
5030 lm
DALI
460 × 240
65
3500
800
71 140
70 833
84 241 40.0 W
5030 lm
DALI
520 × 240
105
4500
800
71 140
70 833
Asymmetrical
Asymmetrical
Flat beam
Please refer to the technical planning data for planning and installation. The current values for LED service life, luminous flux,
maximum ambient temperature and information about the use of BEGA Thermal Management ® are readily available in the
instructions for use and data sheets on our website.
Outdoor luminaires Part 2
Asymmetrical flat beam light distribution · Single · BEGA BugSaver® technology
Anch. unit
Screw-on base
LED
Controllable
A
B
C
D
85 077 19.5 W
1775 lm
DALI DT8 TW
285 × 240
65
3500
800
71 140
70 833
Asymmetrical light distribution · Single · BEGA BugSaver® technology
Anch. unit
Screw-on base
LED
Controllable
A
B
C
D
85 076 19.5 W
2080 lm
DALI DT8 TW
285 × 240
65
3500
800
71 140
70 833
Supplement
Page 31
Illumination
diagrams
231
