Charging units
Charging unit for installation on an existing pole
Connection box
A
B
C
85 097
Single
max. charging output 22 kW
220
235
1420
71 306
85 115
Double
max. charging output 2x22 kW
220
550
1420
71 306
Luminaire pole with integrated charging unit
Protection class IP 54
Aluminium
max. charging output 22 kW
For all e-vehicles with type 2 plug in accordance with IEC 62196 · Compliant with calibration regulations
BEGA luminaire poles can be bolted onto a foundation provided by the customer,
or onto a BEGA anchorage unit. Please order anchorage units as separate accessories.
For more information about BEGA anchorage units, see Page 431.
For a safe electrical connection of the charging unit, we recommend the separately available
connection box 71 306 with residual current automatic cutout and overvoltage protection.
For more information about BEGA connection boxes, see Page 433.
All technical data can be found in the product data sheet on our website.
Pole and housing colour · BEGA Unidure® · Graphite
Charging unit integrated in a luminaire pole with anchorage section
Connection box
H
d
h
Ø
E
kg
85 047
5000
76
100
170
1000
60.0
71 306
Charging units for subsequent addition
to luminaire poles Ø 115 – 135 mm
Protection class IP 54
Aluminium
For all e-vehicles with type 2 plug in accordance with IEC 62196 · Compliant with calibration regulations
Connection box 71 084 for connecting the luminaire included.
For a safe electrical connection of the charging unit, we recommend the separately available
connection box 71 306 with residual current automatic cutout and overvoltage protection.
For the double charging unit, 2 connection boxes are required
For more information about BEGA connection boxes, see Page 433.
All technical data can be found in the product data sheet on our website.
Colour · BEGA Unidure®
Graphite – article number
Silver
– article number + A
Charging unit integrated in a luminaire pole with base plate
Connection box
Anchorage unit
H
d
h
Ø
D
kg
85 046
5000
76
100
170
340
56.5
71 306
70 899
Single
Double
H = Pole height, without anchorage section
d = Pole top diameter
h = Stepped pole top height
Ø = Pole base diameter
D = Diameter of base plate
E = Anchorage section
kg = Total weight
