B
A
B
A
Please refer to the technical planning data for planning and installation. The current values for LED service life, luminous flux,
maximum ambient temperature and information about the use of BEGA Thermal Management ® are readily available in the
instructions for use and data sheets on our website.
Outdoor luminaires Part 2
Garden and pathway luminaires
With safety guard · Light emission 180° · With optional PIR motion and light sensor
Protection class IP 65
Cast aluminium · Opal glass with thread
Luminaires with LED module: on/off, BEGA Smart or DALI controllable power supply units
BEGA Thermal Management®
LED colour temperature: 3000 K – article number + K3 or 4000 K – article number + K4
The luminaires 85 253 and 85 254 can be configured, switched and dimmed via BEGA Smart
to a colour temperature of 3000 K or 4000 K. Luminaires with PIR motion and light sensor can
only be switched, not dimmed via BEGA Smart.
We supply the E 14 or E 27 socket luminaire versions complete with corresponding LED lamps.
Colour temperature: 3000 K – article number + K3
Technical data for BEGA LED lamps can be found on Page 431.
Luminaire colour · BEGA Unidure ®
Graphite – article number
Silver
– article number + A
20-year availability guarantee for replacement parts and LED modules
With safety guard · Light emission 180° · With PIR motion and light sensor
LED
Controllable
Connection
A
B
85 055 with anchorage unit
5.4 W
100 lm
BEGA Smart
Terminals 4 × 4□
110
730
85 057 with screw-on base
5.4 W
100 lm
BEGA Smart
Terminals 4 × 4□
110
730
85 056 with anchorage unit
10.2 W
160 lm
BEGA Smart
Terminals 4 × 4□
140
900
85 058 with screw-on base
10.2 W
160 lm
BEGA Smart
Terminals 4 × 4□
140
900
With safety guard · Light emission 180°
LED
Controllable
Connection
A
B
84 316 with anchorage unit
5.0 W
100 lm
on/off
Terminals 3 × 4□
110
730
84 423 with screw-on base
5.0 W
100 lm
on/off
Terminals 3 × 4□
110
730
• 85 253 with anchorage unit
5.0 W
100 lm
BEGA Smart
Terminals 3 × 4□
110
730
• 85 254 with screw-on base
5.0 W
100 lm
BEGA Smart
Terminals 3 × 4□
110
730
84 317 with anchorage unit
9.5 W
160 lm
DALI
Terminals 5 × 4□
140
900
84 424 with screw-on base
9.5 W
160 lm
DALI
Terminals 5 × 4□
140
900
LED lamp included
Socket
Connection
84 318 with anchorage unit
1 × 4.0 W
55 lm
E 14
Terminals 3 × 4□
110
730
84 425 with screw-on base
1 × 4.0 W
55 lm
E 14
Terminals 3 × 4□
110
730
84 319 with anchorage unit
1 × 8.0 W
125 lm
E 27
Terminals 3 × 4□
140
900
84 426 with screw-on base
1 × 8.0 W
125 lm
E 27
Terminals 3 × 4□
140
900
Garden and pathway luminaires
With safety guard · Light emission 360° · With optional PIR motion and light sensor
Protection class IP 65
Cast aluminium and aluminium · Opal glass with thread
Luminaires with LED module: on/off BEGA Smart or DALI controllable power supply units
BEGA Thermal Management®
LED colour temperature: 3000 K – article number + K3 or 4000 K – article number + K4
The luminaires 85 257 and 85 258 can be configured, switched and dimmed via BEGA Smart
to a colour temperature of 3000 K or 4000 K. Luminaires with PIR motion and light sensor can
only be switched, not dimmed via BEGA Smart.
We supply the E 14 or E 27 socket luminaire versions complete with corresponding LED lamps.
Colour temperature: 3000 K – article number + K3
Technical data for BEGA LED lamps can be found on Page 431.
Luminaire colour · BEGA Unidure ®
Graphite – article number
Silver
– article number + A
20-year availability guarantee for replacement parts and LED modules
With safety guard · Light emission 360° · With PIR motion and light sensor
LED
Controllable
Connection
A
B
85 059
with anchorage unit
5.4 W
190 lm
BEGA Smart
Terminals 4 × 4□
110
730
85 061
with screw-on base
5.4 W
190 lm
BEGA Smart
Terminals 4 × 4□
110
730
85 060
with anchorage unit
10.2 W
330 lm
BEGA Smart
Terminals 4 × 4□
140
900
85 062
with screw-on base
10.2 W
330 lm
BEGA Smart
Terminals 4 × 4□
140
900
With safety guard · Light emission 360°
LED
Controllable
Connection
A
B
84 322 with anchorage unit
5.0 W
190 lm
on/off
Terminals 3 × 4□
110
730
84 429 with screw-on base
5.0 W
190 lm
on/off
Terminals 3 × 4□
110
730
• 85 257 with anchorage unit
5.0 W
190 lm
BEGA Smart
Terminals 3 × 4□
110
730
• 85 258 with screw-on base
5.0 W
190 lm
BEGA Smart
Terminals 3 × 4□
110
730
84 323 with anchorage unit
9.5 W
330 lm
DALI
Terminals 5 × 4□
140
900
84 430 with screw-on base
9.5 W
330 lm
DALI
Terminals 5 × 4□
140
900
LED lamp included
Socket
Connection
84 324 with anchorage unit
1 × 4.0 W
115 lm
E 14
Terminals 3 × 4□
110
730
84 431 with screw-on base
1 × 4.0 W
115 lm
E 14
Terminals 3 × 4□
110
730
84 325 with anchorage unit
1 × 8.0 W
240 lm
E 27
Terminals 3 × 4□
140
900
84 432 with screw-on base
1 × 8.0 W
240 lm
E 27
Terminals 3 × 4□
140
900
Supplement
Page 27
Illumination
diagrams
Supplement
Page 27
Illumination
diagrams
189
