Garden and pathway luminaires
Garden and pathway luminaires
Unshielded · Light emission 360° · Optionally with PIR motion and light sensor
Protection class IP 65 · Cast aluminium and aluminium · Opal glass with thread
Luminaires with LED module: on/off, BEGA Smart or DALI controllable power supply units
BEGA Thermal Management®
LED colour temperature: 3000 K – article number + K3 or 4000 K – article number + K4
The luminaires 85 249 and 85 250 can be configured, switched and dimmed via BEGA Smart
to a colour temperature of 3000 K or 4000 K. Luminaires with PIR motion and light sensor can
only be switched, not dimmed via BEGA Smart.
We supply the E 27 socket luminaire versions complete with corresponding LED lamps.
Colour temperature: 3000 K – article number + K3
Technical data for BEGA LED lamps can be found on Page 431.
Luminaire colour · BEGA Unidure ®
Graphite – article number
Silver
– article number + A
20-year availability guarantee for replacement parts and LED modules
Unshielded · Light emission 360°
LED
Controllable
Connection
A
B
84 310 with anchorage unit
5.0 W
460 lm
on/off
Terminals 3 × 4□
110
730
84 417 with screw-on base
5.0 W
460 lm
on/off
Terminals 3 × 4□
110
730
• 85 249 with anchorage unit
5.0 W
460 lm
BEGA Smart
Terminals 3 × 4□
110
730
• 85 250 with screw-on base
5.0 W
460 lm
BEGA Smart
Terminals 3 × 4□
110
730
84 311 with anchorage unit
9.5 W
870 lm
DALI
Terminals 5 × 4□
140
900
84 418 with screw-on base
9.5 W
870 lm
DALI
Terminals 5 × 4□
140
900
LED lamp included
Socket
Connection
84 312 with anchorage unit
1 × 7.0 W
510 lm
E 27
Terminals 3 × 4□
110
730
84 419 with screw-on base
1 × 7.0 W
510 lm
E 27
Terminals 3 × 4□
110
730
84 313 with anchorage unit
1 × 12.0 W
880 lm
E 27
Terminals 3 × 4□
140
900
84 420 with screw-on base
1 × 12.0 W
880 lm
E 27
Terminals 3 × 4□
140
900
Unshielded · Light emission 360° · With PIR motion and light sensor
LED
Controllable
Connection
A
B
85 051 with anchorage unit
5.4 W
460 lm
BEGA Smart
Terminals 4 × 4□
110
730
85 053 with screw-on base
5.4 W
460 lm
BEGA Smart
Terminals 4 × 4□
110
730
85 052 with anchorage unit
10.2 W
870 lm
BEGA Smart
Terminals 4 × 4□
140
900
85 054 with screw-on base
10.2 W
870 lm
BEGA Smart
Terminals 4 × 4□
140
900
Intuitive configuration via app
The garden and pathway luminaires with an integrated passive
infrared motion and light sensor are extremely easy to configure
via Bluetooth and the free app BEGA Smart.
After sunset and when motion is detected, additional luminaires
that are networked via BEGA Smart (for example the matching
garden and pathway luminaires without sensors) can be
controlled. Alternatively, other luminaires can be controlled via
the integrated relay output.
Find out more at bega.com/smart
The luminaires of this series are secured in the ground with an anchorage unit made of hot-dip
galvanised steel, or they are bolted onto a construction side foundation using a screw-on base.
Anchorage units and screw-on bases are included in the scope of delivery.
Screw-on base
For the permanent installation of BEGA garden and pathway luminaires on e.g.
on-site foundations or on other paved surfaces.
The screw-on base made of hot-dip galvanised steel is included with the luminaire.
For this type of installation, an underground cable is inserted into the anchorage unit from
below. The socket is bolted onto the mounting surface. The luminaire is then connected
with a line connector and fixed to the screw-on base.
Anchorage unit
For the permanent installation of BEGA garden and pathway luminaires in a flowerbed or an
unpaved surface, for example.
The anchorage unit made of hot-dip galvanised steel is included in the scope of delivery of
the luminaire.
With this type of installation, an underground cable is routed into the anchorage unit from
below. The underground cable and anchorage unit are set in concrete. The luminaire is then
connected, placed on the anchorage unit and bolted in position.
Supplement
Page 27
Illumination
diagrams
• New in the range
