Bollards
Shielded light
Protection class IP 65
Cast aluminium · Safety glass
Reflector made of pure anodised aluminium · BEGA Constant Optics®
DALI controllable power supply units · BEGA Thermal Management®
These luminaires emit less than 1% of the light into the upper half-space of the luminaires.
These BEGA bollards are equipped with an alignable mounting system.
It can either be bolted onto a foundation provided by the customer, or onto
a BEGA anchorage unit. Please order anchorage units as separate accessories.
For more information about BEGA anchorage units, see Page 431.
LED colour temperature: 3000 K – article number + K3 or 4000 K – article number + K4
Luminaire colour · BEGA Unidure®
Graphite – article number
Silver
– article number + A
20-year availability guarantee for replacement parts and LED modules
LED
Controllable
Connection box
A
B
Anch. unit
84 061 22.0 W
1450 lm
DALI
70 632
165
1000
70 895
84 062 33.0 W
1805 lm
DALI
70 632
220
1200
70 896
Bollard
Shielded light
Protection class IP 65
Cast aluminium · Safety glass
Reflector made of pure anodised aluminium · BEGA Constant Optics®
BEGA Ultimate Driver ® · DALI controllable · BEGA Thermal Management ®
These luminaires emit less than 1% of the light into the upper half-space of the luminaires.
These BEGA bollards are equipped with an alignable mounting system.
It can either be bolted onto a foundation provided by the customer, or onto
a BEGA anchorage unit. Please order anchorage units as separate accessories.
For more information about BEGA anchorage units, see Page 431.
LED colour temperature: 3000 K – article number + K3 or 4000 K – article number + K4
Luminaire colour · BEGA Unidure®
Graphite – article number
Silver
– article number + A
20-year availability guarantee for replacement parts and LED modules
Fixed symmetrical light distribution
Anchorage unit
LED
Controllable
Connection
A
B
C
88 066 9.5 W
600 lm
DALI
Terminals 5 × 4□
270
600
140
70 895
Adjustable light distribution
Anchorage unit
LED
Controllable
Connection
A
B
C
88 062 20.6 W
1770 lm
DALI
Terminals 5 × 4□
270
1100
140
70 895
Bollards
Fixed symmetrical light distribution
or adjustable light distribution
Protection class IP 65
Cast aluminium · Safety glass
Reflector made of pure anodised aluminium · BEGA Constant Optics®
DALI controllable power supply units · BEGA Thermal Management®
88 066 Fixed symmetrical light distribution
88 062 Optical system adjustable to 0°, 15° or 30°
These BEGA bollards are equipped with an alignable mounting system.
It can either be bolted onto a foundation provided by the customer, or onto
a BEGA anchorage unit. Please order anchorage units as separate accessories.
For more information about BEGA anchorage units, see Page 431.
LED colour temperature: 3000 K – article number + K3 or 4000 K – article number + K4
Luminaire colour · BEGA Unidure®
Graphite – article number
Silver
– article number + A
20-year availability guarantee for replacement parts and LED modules
88 066
88 062
88 062
0°, 15° or 30°
adjustable
88 066
Please refer to the technical planning data for planning and installation. The current values for LED service life, luminous flux,
maximum ambient temperature and information about the use of BEGA Thermal Management ® are readily available in the
instructions for use and data sheets on our website.
LED
Controllable
Connection box
A
B
Anch. unit
84 063 22.0 W
1440 lm
DALI
70 632
160 × 160
1000
70 895
