Bollards
Asymmetrical or flat beam light distribution
Protection class IP 65
Cast aluminium · Safety glass
Reflector made of pure anodised aluminium · BEGA Constant Optics®
BEGA Ultimate Driver® · DALI controllable · BEGA Thermal Management®
These luminaires emit less than 1% of the light into the upper half-space of the luminaires.
These BEGA bollards are equipped with an alignable mounting system. It can either
be bolted onto a foundation provided by the customer, or onto a BEGA anchorage unit.
Please order anchorage units as separate accessories.
For more information about BEGA anchorage units, see Page 431.
LED colour temperature: 3000 K – article number + K3 or 4000 K – article number + K4
Luminaire colour · BEGA Unidure®
Graphite – article number
Silver
– article number + A
20-year availability guarantee for replacement parts and LED modules
Asymmetrical light distribution
Anchorage unit
LED
Controllable
Connection
A
B
84 238 13.1 W
1605 lm
DALI
Terminals 5 × 4□
160 × 160
945
70 895
Flat beam light distribution
Anchorage unit
LED
Controllable
Connection
A
B
84 750 7.0 W
655 lm
DALI
Terminals 5 × 4□
160 × 160
495
70 895
84 220 13.1 W
1435 lm
DALI
Terminals 5 × 4□
160 × 160
945
70 895
Flat beam
light distribution
Asymmetrical
light distribution
Flat beam
light distribution
Asymmetrical
light distribution
Please refer to the technical planning data for planning and installation. The current values for LED service life, luminous flux,
maximum ambient temperature and information about the use of BEGA Thermal Management ® are readily available in the
instructions for use and data sheets on our website.
Bollards
Asymmetrical or flat beam light distribution
Protection class IP 65
Cast aluminium · Safety glass
Reflector made of pure anodised aluminium · BEGA Constant Optics®
BEGA Ultimate Driver® · DALI controllable · BEGA Thermal Management®
These luminaires emit less than 1% of the light into the upper half-space of the luminaires.
These BEGA bollards are equipped with an alignable mounting system. It can either
be bolted onto a foundation provided by the customer, or onto a BEGA anchorage unit.
Please order anchorage units as separate accessories.
For more information about BEGA anchorage units, see Page 431.
LED colour temperature: 3000 K – article number + K3 or 4000 K – article number + K4
Luminaire colour · BEGA Unidure®
Graphite – article number
Silver
– article number + A
20-year availability guarantee for replacement parts and LED modules
Asymmetrical light distribution
Anchorage unit
LED
Controllable
Connection
A
B
84 239 13.1 W
1695 lm
DALI
Terminals 5 × 4□
Ø 190 1000
70 895
Flat beam light distribution
Anchorage unit
LED
Controllable
Connection
A
B
84 749 7.0 W
665 lm
DALI
Terminals 5 × 4□
Ø 190
550
70 895
99 058 13.1 W
1415 lm
DALI
Terminals 5 × 4□
Ø 190 1000
70 895
Outdoor luminaires Part 2
