You will find all bollard tubes for the bollard heads of Pages 170 to 176 here.
The brief description offers a condensed overview of their functions. Detailed technical
and lighting data for all the system components can be found in the data sheets and
instructions for use on our website.
Bollard tubes with safety sockets have a type F socket (German/European system)
as standard. On request, we can also supply the bollard tubes with other socket types
for the same price. For more information about all socket types, see Page 432.
Ø 140
Bollard tubes
Connection box
H
Anch. unit
99 614 Ø 140
Without components · Low
Terminals 3 × 4
350
70 894
99 620 Ø 140
Without components · High
Terminals 3 × 4
655
70 894
84 476 Ø 140
Without components · Accoya® wood · High
Terminals 3 × 4
655
70 894
84 759 Ø 140
With PIR motion and light sensor
71084
655
70 894
84 915 Ø 140
With safety socket 250 V type F
70 629
655
70 894
A
E
J
Ø 190
Bollard tubes
Connection box
H
Anch. unit
99 615 Ø 190
Without components · Low
Terminals 3 × 4
365
70 895
99 622 Ø 190
Without components · High
71084
815
70 896
84 464 Ø 190
Without components · Accoya® wood · High
71084
815
70 896
84 634 Ø 190
With single emergency lighting battery 10 W · 3 h
71 601
815
70 896
84 760 Ø 190
With PIR motion and light sensor
71084
815
70 896
84 170 Ø 190
With PIR motion and light sensor · DALI
71084
815
70 896
84 833 Ø 190
With LED floodlight 23.0 W · 2585 lm · β = 18°
71 084
815
70 896
84 998 Ø 190
With additional water connection G 1/2
Terminals 5 × 4
815
70 896
84 916 Ø 190
With safety socket 250 V type F
70 629
815
70 896
99 626 Ø 190
With 2 safety sockets 250 V type F
70 869
815
70 896
Behind a lockable door
A
F
H
System bollards
Order a bollard head of your choice and add a matching bollard tube to the order.
Both modules can be connected quickly and easily during the installation.
BEGA bollard tubes are bolted with a mounting plate onto a foundation provided by the customer
or an anchorage unit made of hot-dip galvanised steel. The mounting system can be used to
align the luminaire.
Anchorage units are accessories and must be ordered separately. For more information
about BEGA anchorage units, see Page 431.
BEGA Unidure ®
Graphite – article number
Silver
– article number + A
B
B
D
E
I
J
K
Ø 265
L
B
I
Bollard tubes
Connection box
H
Anch. unit
99 619 Ø 265
Without components · Low
Terminals 3 × 4
375
70 896
99 624 Ø 265
Without components · High
71084
875
70 896
84 465 Ø 265
Without components · Accoya® wood · High
71084
875
70 896
84 636 Ø 265
With single emergency lighting battery 10 W · 3 h
71 601
875
70 896
84 761 Ø 265
With PIR motion and light sensor
71084
875
70 896
84 173 Ø 265
With PIR motion and light sensor · DALI
71084
875
70 896
84 623 Ø 265
Drive-through protection up to 7.5 t · 50 km/h · Foundation height 800 mm
70 632
875
inklusive
84 303 Ø 265
Drive-through protection up to 7.5 t · 50 km/h · Foundation height 380 mm
70 632
875
inklusive
84 999 Ø 265
With additional water connection G 3/4
Terminals 5 × 4
875
70 896
99 627 Ø 265
With 2 safety sockets 250 V type F
70 869
875
70 896
Behind a lockable door
84 095 Ø 265
With 2 CEE sockets 400 V, with 3 CEE sockets 250 V
1150
70 896
With 3 safety sockets 250 V type F, with RCD
With 2 automatic cutouts 3-pole
With 6 automatic cutouts 1-pole
84 096 Ø 265
Without installation inserts with 2 fuse boxes, 8-part
1150
70 896
85 029 Ø 265
With charging module insert for electric vehicles (Type 2) charging output max. 22 kW
1150
70 896
G
M
A
F
D
E
K
