DarkSky
B
A
B
C
A
A
D
B
A
On-ground luminaires
Light emission 180° or 360°
Protection class IP 67
Cast aluminium · Crystal glass
Reflector made of pure anodised aluminium · Optical silicone lens
BEGA Hybrid Optics ®
on/off or DALI controllable power supply units
BEGA Thermal Management®
LED colour temperature: 3000 K – article number + K3 or 4000 K – article number + K4
Luminaire colour · BEGA Unidure®
Graphite – article number
Silver
– article number + A
20-year availability guarantee for replacement parts and LED modules
Light emission 180°
Connection housing
LED
Controllable
A
B
84 752 6.6 W
370 lm
on/off
170
120
71 246
84 355 13.8 W
605 lm
DALI
210
150
71 246
Light emission 360°
Connection housing
LED
Controllable
A
B
84 753 15.4 W
1210 lm
on/off
170
120
71 246
84 357 22.5 W
1535 lm
DALI
210
150
71 246
We offer a connection housing as an
accessory for different requirements
at the installation site. This allows the
luminaires to be mounted on unpaved
surfaces. For more information, see
Page 430.
180°
360°
Please refer to the technical planning data for planning and installation. The current values for LED service life, luminous flux,
maximum ambient temperature and information about the use of BEGA Thermal Management ® are readily available in the
instructions for use and data sheets on our website.
Flat beam light distribution
Anchorage unit
LED
Controllable
A
B
C
D
77 735 9.5 W
505 lm
on/off
200
210
60
125
70 894
On-ground luminaires
Flat beam light distribution
Protection class IP 65
Cast aluminium · Crystal glass
BEGA Ultimate Driver ® · on/off
BEGA Thermal Management®
LED colour temperature: 3000 K – article number + K3 or 4000 K – article number + K4
Luminaire colour · BEGA Unidure®
Graphite – article number
Silver
– article number + A
20-year availability guarantee for replacement parts and LED modules
Outdoor luminaires Part 2
Flat beam
light distribution
On-ground luminaires
Light emission 360°
Protection class IP 65
Cast aluminium · Safety glass
Reflector surface made of pure aluminium · BEGA Constant Optics®
BEGA Ultimate Driver® · DALI controllable
BEGA Thermal Management®
These luminaires emit less than 1% of the light into the upper half-space of the luminaires.
LED colour temperature: 3000 K – article number + K3 or 4000 K – article number + K4
Luminaire colour · BEGA Unidure®
Graphite – article number
Silver
– article number + A
20 year availability guarantee for replacements
and LED modules
Light emission 360°
Connection housing
LED
Controllable
A
B
• 85 222 15.5 W
800 lm
DALI
350
190
71 246
360°
We offer a connection housing as an
accessory for different requirements
at the installation site. This allows the
luminaires to be mounted on unpaved
surfaces. For more information, see
Page 430.
161
