Please refer to the technical planning data for planning and installation. The current values for LED service life, luminous flux,
maximum ambient temperature and information about the use of BEGA Thermal Management® are readily available in the
instructions for use and data sheets on our website.
Outdoor luminaires Part 2
On-ground luminaires · Wall washers
with fixed light distribution for the illumination of vertical surfaces
Protection class IP 67 · Cast aluminium · Safety glass
Reflector made of pure anodised aluminium · BEGA Constant Optics®
Integrated water stop and connecting cable
DALI controllable power supply units · BEGA Thermal Management®
The RGBW luminaires in this series can be controlled by DALI colour light control (DT 8, RGBWAF, xy, TC).
Suitable DALI system components can be found on Pages 412 to 417.
We offer a connection housing as an accessory to meet any requirements at the installation site.
The luminaires can therefore be installed on unpaved substrates. We recommend using the BEGA
distribution box 70 730 if through-wiring to another luminaire is required. The distribution box is
suitable for installation in the connection housing. For more information about connection housings
and distribution boxes, see Page 430.
LED colour temperature: 3000 K – article number + K3 or
4000 K – article number + K4
Luminaire colour · BEGA Tricoat® · Graphite
20-year availability guarantee for replacement parts and LED modules
On-ground luminaire · Wall washers
Accessories
LED
Controllable
A
B
Connection
housing
84 174 33.2 W
4085 lm
DALI
260 x 250
75
71 246
RGBW on-ground luminaire · Wall washers
Accessories
LED
Controllable
A
B
Connection
housing
84 874 26.6 W
1,910 lm
DALI DT 8
260 x 250
75
71 246
On-ground luminaires · Wall washers
for the illumination of vertical surfaces
On-ground luminaires are a great alternative wherever drive-over resistance or a flush surface
installation are not necessary. They are considerably easier to install than in-ground luminaires.
In contrast to conventional floodlights, which can be adjusted freely, the closed housings of these
luminaires offer additional advantages.
The wall washers make it possible to illuminate a vertical surface, such as a façade, almost completely
from the ground to the lower edge of the roof. The lower limit of the light distribution is linear, without
the usual “light cone” seen with in-ground floodlights.
On-ground luminaires · Wall washers
with adjustable light distribution for the illumination of vertical surfaces
Protection class IP 67 · Cast aluminium · Safety glass
Reflector made of pure anodised aluminium · BEGA Constant Optics®
Integrated water stop and connecting cable
DALI controllable power supply units · BEGA Thermal Management®
The RGBW luminaires in this series can be controlled by DALI colour light control (DT 8, RGBWAF, xy, TC).
DALI system components can be found on Pages 412 to 417.
We offer a connection housing as an accessory to meet any requirements at the installation site.
The luminaires can therefore be installed on unpaved substrates. We recommend using the BEGA
distribution box 70 730 if through-wiring to another luminaire is required. The distribution box is
suitable for installation in the connection housing. For more information about connection housings
and distribution boxes, see Page 430.
LED colour temperature: 3000 K – article number + K3 or
4000 K – article number + K4
Luminaire colour · BEGA Tricoat® · Graphite
20-year availability guarantee for replacement parts and LED modules
On-ground luminaires · Adjustable light distribution
Accessories
LED
Controllable
A
B
Connection
housing
• 85 118 31.5 W
2605 lm
DALI
265 x 255 105
71 246
RGBW on-ground luminaire · Adjustable light distribution
Accessories
LED
Controllable
A
B
Connection
housing
• 85 119 31.0 W
1265 lm
DALI DT 8
265 x 255 105
71 246
