C
A
B
C
A
B
0
°-
3
0
°
3t
In-ground luminaires
Pressure load
3000 kg
Material
Stainless steel · Cast stainless steel
Protection class
IP 68 · 10 m
Installation depth
130 mm
Size Ø
205 · 260 mm
In-ground luminaires
for installation situations with shallow installation depths and for flush installations
Trim ring and luminaire housing made of stainless steel and cast stainless steel · Safety glass
Floodlights with reflectors made of pure anodised aluminium · BEGA Constant Optics®
BEGA Ultimate Driver® · on/off or DALI controllable
BEGA Thermal Management®
Integrated water stop and connecting cable
All luminaires with the extension R after the article number are supplied
with skid-blocking glass in compliance with DIN 51130 R 13.
LED colour temperature: 2700 K – article number + K27 or 3000 K – article number + K3
On request, the luminaires are available in the light colours green, blue, amber and red.
20-year availability guarantee for replacement parts and LED modules
Location luminaires
LED
Controllable
max. ta
A
B
C
77 162 4.1 W
70 lm
on/off
50 °C
205
210
130
77 163 5.0 W
95 lm
on/off
50 °C
260
270
130
Floodlights · Symmetrical light distribution
LED
Controllable
β
max. ta
A
B
C
77 961 10.0 W
1020 lm
DALI
20°
50 °C
205
210
130
77 964 16.0 W
1875 lm
DALI
27°
50 °C
260
270
130
Floodlights · Asymmetrical light distribution
LED
Controllable
β
max. ta
A
B
C
77 971 10.0 W
1050 lm
DALI
28/29°
50 °C
205
210
130
77 979 16.0 W
1995 lm
DALI
28/27°
50 °C
260
270
130
Location luminaires
Floodlights
Symmetrical
Floodlights
Asymmetrical
Floodlights
Adjustable
Floodlights · 0°– 30° adjustable ·180° rotation · Symmetrical light distribution
Accessories
LED
Controllable
β
max. ta
A
B
C
77 177 10.0 W
800 lm
DALI
11°
50 °C
205
210
130
70 271
70 272
77 920 13.8 W
1055 lm
DALI
13°
50 °C
260
270
130
70 273
70 274
max. ta
50 °C
β = Half beam angle max. ta = maximum permissible ambient temperature Diffuser lenses
wide beam
Flat beam
In-ground luminaires
for installation situations with shallow installation depths and for flush installations
Thanks to their low height, these luminaires are particularly suitable for areas where only a limited
installation depth is available, e.g. parking decks or suspended ceilings, both indoors and out.
Before the luminaires are installed, the customer must lay a foundation to absorb the pressure
loads of the luminaires.
The luminaires can be driven over by vehicles with pneumatic tyres.
Supplement
Page 22
Illumination
diagrams
152
