A
B
C
2t
Pressure load
2000 kg
Material
Stainless steel
Protection class
IP 68 · 10 m
Installation depth
80 – 310 mm
Size Ø
145 - 410 mm
In-ground luminaires
for installation in ground surfaces
Trim ring and luminaire housing made of stainless steel · Safety glass
Reflector surface made of pure aluminium
BEGA Ultimate Driver ® · BEGA Thermal Management ®
Integrated water stop and connecting cable
84 629 · 84 630 · 84 631 with internal louvres and ultra-black coating for maximum light absorption
Polymer lens made of BEGA NeoGlass® · BEGA Ultradark Optics®
BEGA Hybrid Optics®
Floodlights with symmetrically and asymmetrically wide beam light distribution
and RGBW luminaires: BEGA Constant Optics®
Matrix floodlights with dynamic light distribution can be adjusted with the BEGA Tool app.
The luminaires can call up a predefined setting using on/off operation, or call up multiple settings
saved as scenarios via DALI.
The RGBW luminaires can be controlled via a DALI colour light control (DT 8, RGBWAF, xy, TC).
Suitable DALI system components can be found on Pages 412 to 417.
All luminaires with the extension R after the article number are supplied
with skid-blocking glass in compliance with DIN 51130 R 13.
LED colour temperature: 2700 K – article number + K27 or 3000 K – article number + K3
20-year availability guarantee for replacement parts and LED modules
If the luminaires are to be
used with an installation
housing, a foundation with
drainage must be provided
by the customer.
In-ground luminaires
Wall washers · Asymmetrical very wide beam light distribution
LED
Controllable
β
max. ta
A
B
C
84 767
5.1 W
420 lm
on/off
45/52°
40 °C
145
95
140
70 693
84 153
9.5 W
790 lm
DALI
40/55°
50 °C
205
140
165
70 680
84 154
16.0 W
1405 lm
DALI
41/54°
50 °C
245
175
185
70 687
84 155
30.0 W
2785 lm
DALI
40/55°
50 °C
330
240
225
70 688
Location luminaires
LED
Controllable
max. ta
A
B
C
77 055
2.7 W
95 lm
on/off
55 °C
145
95
80
70 693
77 056
3.9 W
225 lm
on/off
45 °C
205
140
80
70 680
77 057
4.8 W
185 lm
on/off
50 °C
245
175
90
70 687
77 058
9.2 W
600 lm
on/off
45 °C
330
240
100
70 688
Floodlights · Symmetrical light distribution
Focused very
narrow beam
LED
Controllable
β
max. ta
A
B
C
85 038
16.0 W
505 lm
DALI
5°
45 °C
280
200
185
70 694
85 039
33.0 W
975 lm
DALI
5°
50 °C
330
240
225
70 688
85 040
58.0 W
2220 lm
DALI
5°
50 °C
410
325
310
70 699
Wide beam
84 554
5.0 W
470 lm
on/off
20°
40 °C
145
95
140
70 693
84 555
13.0 W
1415 lm
DALI
22°
55 °C
205
140
165
70 680
84 556
26.2 W
2565 lm
DALI
17°
50 °C
245
175
185
70 687
84 557
38.4 W
4055 lm
DALI
21°
50 °C
330
240
225
70 688
Very wide beam
84 572
5.1 W
440 lm
on/off
56°
30 °C
145
95
140
70 693
84 307
9.5 W
840 lm
DALI
53°
50 °C
205
140
165
70 680
84 308
16.0 W
1535 lm
DALI
54°
50 °C
245
175
185
70 687
84 309
30.0 W
2960 lm
DALI
54°
50 °C
330
240
225
70 688
• New to the range β = Half beam angle max. ta = maximum permissible ambient temperature
Installation housing
Diffuser lenses · flat beam
Louvre
max. ta
30 – 55 °C
In-ground luminaires
for installation in ground surfaces
An extensive and efficient series of in-ground luminaires for use both indoors and out. Different light
characteristics and light outputs are available for your planning work. The luminaire housings are
made entirely of stainless steel.
Depending on the installation situation, the luminaires can be installed using installation housings or
simply “floating”, e.g. in gravel, lawns, flowerbeds or paved surfaces. If the luminaires are to be used
with an installation housing, a foundation with drainage must be provided by the customer.
The luminaires in this series can be driven over by vehicles with pneumatic tyres.
Supplement
Page 21
Illumination
diagrams
148
