A
C
B
4 m
A
C
B
4 m
2 m
A
C
B
A
C
B
B
C
Underwater floodlights with integrated power supply unit · 230 V AC · Safety class I
LED
Controllable
β
A
B
C
99 415 20.8 W
2170 lm
on/off
16°
220
195
270
99 445 20.8 W
2300 lm
on/off
54°
220
195
270
Underwater floodlights without power supply unit · 24 V DC · Safety class III
LED
Power supply unit
A
B
C
99 115 13.9 W 1425 lm
without*
135
65
170
99 117 18.3 W 1835 lm
without*
190
95
235
84 399 62.0 W 4060 lm
without*
190
95
235
Underwater floodlights
with integrated power supply unit
Protection class IP 68 20 m
Supply voltage 230 V AC · Safety class I
BEGA Thermal Management®
Stainless steel, material no. 1.4301, electropolished · Safety glass
Reflector made of pure anodised aluminium · BEGA Constant Optics®
Water-resistant cable: Cable length 4 m
Mounting bracket for horizontal and vertical floodlight adjustment
LED colour temperature: 3000 K – article number + K3
20-year availability guarantee for replacement parts and LED modules
Underwater floodlights
without power supply unit
Protection class IP 68 20 m
Supply voltage 24 V DC · Safety class III
Stainless steel, material no. 1.4301, electropolished · Safety glass
Reflector made of pure anodised aluminium · BEGA Constant Optics®
Water-resistant cable: Cable length 4 m
An external 24 V DC safety power supply unit is required to operate the luminaires.
Mounting bracket for horizontal and vertical floodlight adjustment
LED colour temperature: 3000 K – article number + K3
20-year availability guarantee for replacement parts and LED modules
One ready-to-connect underwater floodlight and power supply unit
LED
Controllable
A
B
C
99 524 19.5 W
1425 lm
on/off
135
65
170
Two ready-to-connect underwater floodlights and power supply unit
LED
Controllable
A
B
C
99 526 40.0 W
2850 lm
on/off
135
65
170
Underwater floodlights ready for connection
Consisting of one or two floodlights
with external power supply unit and connecting cable with mains plug
Protection class IP 68 4 m · Safety class III
Stainless steel, material no. 1.4301, electropolished · Safety glass
Reflector made of pure anodised aluminium · BEGA Constant Optics®
Water-resistant cable: Cable length 4 m
on/off power supply units · BEGA Thermal Management®
Mounting bracket for horizontal and vertical floodlight adjustment
Safety power supply unit: Protection class IP 66 · Safety class II
2 m connecting cable with type F/E mains plug · Safety plug IP 44
LED colour temperature: 3000 K – article number + K3
20-year availability guarantee for replacement parts and LED modules
* Suitable 24 V DC safety power supply units can be found on Page 136.
Please refer to the technical planning data for planning and installation. The current values for LED service life, luminous flux,
maximum ambient temperature and information about the use of BEGA Thermal Management® are readily available in the
instructions for use and data sheets on our website.
Outdoor luminaires Part 2
Supplement
Page 19
Illumination
diagrams
Supplement
Page 19
Illumination
diagrams
Supplement
Page 19
Illumination
diagrams
139
