B
A
C
B
A
C
High-performance floodlights for high ambient temperatures
Symmetrically focused, very narrow beam, narrow beam, wide beam or flat beam light distribution
Protection class IP 67 · Cast aluminium and stainless steel · Safety glass
Reflector surface made of pure aluminium · Optical silicone lens
Mounting bracket using 1 central hole Ø 21.5 mm, 2 holes Ø 9 mm · Distance apart 80 mm
and 2 holes Ø 11.5 mm · Distance apart 200 mm
BEGA Ultimate Driver ® · DALI controllable and output manually adjustable in four steps 100 % · 70 % · 50 % · 30 %
Ambient temperature max. ta = 40/45/50 °C · BEGA Thermal Management ®
Shields and internal louvres are available as accessories for these floodlights.
These can be used individually or in combination.
You will find suitable accessories for each floodlight on our website under the relevant luminaire article number.
Other accessories for high-performance floodlights can be found on Pages 428 to 429.
The RGBW floodlights of this series can be controlled via DALI colour light control (DT 8, RGBWAF, xy).
Matching DALI system components can be found on Pages 412 to 417.
LED colour temperature:
2200 K – article number + K22, 3000 K – article number + K3 or 4000 K – article number + K4
Luminaires with symmetrical very narrow beam light distribution: 3000 K – article number + K3 or 4000 K – article number + K4
Luminaire colour · BEGA Unidure® · Graphite
20-year availability guarantee for replacement parts and LED modules
max. ta = maximum permissible ambient temperature β = Half beam angle
Shield
Louvre
High-performance floodlights
Symmetrically focused light distribution with reduced diffuse light percentage · BEGA Hybrid Optics®
Accessories
LED
max.ta
Controllable
β
A
B
C
84 536 132.0 W
7 345 lm
45 °C
DALI
11°
375
410
235
71 110
Integrated
84 540 312.0 W
14 785 lm
40 °C
DALI
10°
495
530
310
71 101
Integrated
Symmetrical narrow beam light distribution · BEGA Constant Optics ®
Accessories
LED
max.ta
Controllable
β
A
B
C
84 537 132.0 W
14 370 lm
45 °C
DALI
17°
375
410
235
71 110
71 109
84 541 326.0 W
40 275 lm
45 °C
DALI
21°
495
530
310
71 101
71 105
Symmetrical wide beam light distribution · BEGA Constant Optics ®
Accessories
LED
max.ta
Controllable
β
A
B
C
84 538 132.0 W
14 900 lm
45 °C
DALI
45°
375
410
235
71 110
84 542 326.0 W
41 150 lm
45 °C
DALI
48°
495
530
310
71 101
Symmetrical flat beam light distribution · BEGA Hybrid Optics®
Accessories
LED
max.ta
Controllable
β
A
B
C
84 539 132.0 W
7 120 lm
45 °C
DALI
12/43°
375
410
235
71 110
Integrated
84 543 312.0 W
14 700 lm
40 °C
DALI
11/54°
495
530
310
71 101
Integrated
RGBW · Symmetrical narrow beam light distribution · BEGA Constant Optics ®
Accessories
LED
max.ta
Controllable
β
A
B
C
84 550 132.0 W
8 340 lm
45 °C
DALI DT 8
17°
375
410
235
71 110
71 109
84 551 260.0 W
16 385 lm
45 °C
DALI DT 8
19°
495
530
310
71 101
71 105
RGBW · Symmetrical wide beam light distribution · BEGA Constant Optics ®
Accessories
LED
max.ta
Controllable
β
A
B
C
84 552 132.0 W
8 335 lm
45 °C
DALI DT 8
47°
375
410
235
71 110
84 553 260.0 W
16 050 lm
45 °C
DALI DT 8
47°
495
530
310
71 101
Symmetrical very narrow beam light distribution · BEGA Hybrid Optics®
Accessories
LED
max.ta
Controllable
β
A
B
C
84 739 138.5 W
13 590 lm
50 °C
DALI
8°
375
410
235
71 110
71 109
84 740 279.0 W
29 085 lm
50 °C
DALI
8°
495
530
310
71 101
71 221
Supplement
Page 17
Illumination
diagrams
124
