DarkSky
A
B
C
Wall luminaires · Directed light
These cylindrical wall luminaires in two different sizes and light
outputs, respectively, help to illuminate walls, facades and
structures.
Narrow beam or wide beam light distribution in various sizes or
with light emission on one or two sides: these wall luminaires are
the perfect solution for any requirement. The luminaires can be
installed in any burning position. This allows the illumination of
surfaces adjacent to the installation surface, e.g. ceilings, vaults,
canopies and cantilever plates.
Luminaires in this series with only a downward-directed light
emission emit no light into the upper half-space of the luminaire,
helping to preserve the darkness of the night sky.
Protection class
IP 65
Material
Cast aluminium · Safety glass
Reflector surface made of pure aluminium
BEGA Thermal Management ®
protects the luminaires from overheating
due to excessive ambient temperatures
Controllable
on/off
Lamp
BEGA LED Module
LED colour temperature
3000 K
Luminaire colour
BEGA Unidure®
Graphite
Article number
Silver
Article number + A
White
Article number + W
The half beam angle β describes the size of the light cone with which an object or surface is actually illuminated. Luminaires
with wider half beam angles should be chosen for short lighting distances, a focused light is recommended for larger distances.
Narrow beam
β
A
B
C
24 724 K3
5.0 W
185 lm
22°
80
160
105
24 725 K3
9.5 W
490 lm
12°
115
195
155
Very wide beam
β
A
B
C
24 727 K3
5.0 W
485 lm
70°
80
160
105
24 728 K3
9.5 W
1045 lm
72°
115
195
155
Narrow beam · Narrow beam
β
A
B
C
24 517 K3
9.0 W
370 lm
22°
80
160
105
24 536 K3
19.0 W
980 lm
12°
115
195
155
Very wide beam · Very wide beam
β
A
B
C
24 518 K3
9.0 W
970 lm
70°
80
160
105
24 480 K3
19.0 W
2090 lm
72°
115
195
155
Narrow beam · Very wide beam
β
A
B
C
24 519 K3
9.0 W
675 lm
22°/70°
80
160
105
24 515 K3
19.0 W
1535 lm
12°/72°
115
195
155
63
