A
B
Protection class
IP 65
Material
Cast aluminium · Safety glass
Reflector surface made of pure aluminium
BEGA Thermal Management®
protects the luminaires from overheating
due to excessive ambient temperatures
Controllable
on/off
Lamp
BEGA LED Module
LED colour temperature
3000 K
Luminaire colour
BEGA Unidure®
Ceiling luminaires
Very compact and efficient ceiling luminaires available with
four light distribution types. The symmetrical light distribution
is comparable to the light cone of a floodlight and is available
with three different light characteristics. Luminaires with
asymmetrical light distribution are used for the illuminate of
wall surfaces. Their clear geometric shapes create highlights
for the interior design theme.
Graphite
Article number
White
Article number + W
Page 23
The half beam angle β describes the size of the light cone with which an object or surface is actually illuminated. Luminaires
with wider half beam angles should be chosen for short lighting distances, a focused light is recommended for larger distances.
Symmetrical narrow beam
β
A
B
66 151 K3
4.1 W
350 lm
24°
95 × 95
90
66 153 K3
9.5 W
760 lm
27°
95 × 95
90
Symmetrical wide beam
β
A
B
66 157 K3
4.1 W
425 lm
40°
95 × 95
90
66 158 K3
9.5 W
970 lm
41°
95 × 95
90
Symmetrical very wide beam
β
A
B
24 464 K3
4.1 W
405 lm
90°
95 × 95
90
24 465 K3
9.5 W
900 lm
90°
95 × 95
90
Asymmetrical wide beam
β
A
B
24 056 K3
4.1 W
335 lm
50°/52°
95 × 95
90
24 057 K3
9.5 W
820 lm
46°/52°
95 × 95
90
39
