P0377
A
B
Recessed ceiling luminaires
Compact downlights with a flat, cast aluminium trim ring
Light from the ceiling can be of benefit for the surroundings.
Just like floodlights, these recessed ceiling luminaires are available
with rotationally symmetrical light distribution and a narrow beam,
wide beam or very wide beam. An asymmetrical light distribution
is particularly well suited for the illumination of wall surfaces.
The highly efficient recessed ceiling luminaires come with external,
DALI controllable power supply units.
Suitable installation housings are available for installations in
concrete ceilings. Detailed information can be found on bega.com
in the instructions for use for these luminaires.
On Pages 31 and 35, you will find luminaires of the same light
distribution, but with various trim ring finishes.
Protection class
IP 65
Material
Cast aluminium · Safety glass
Pure aluminium reflector surface
Optical silicone lens
BEGA Thermal Management®
protects the luminaires from overheating
due to excessive ambient temperatures
Controllable
External DALI controllable
power supply unit included
Lamp
BEGA LED Module
LED colour temperature
3000 K
Luminaire colour
BEGA Unidure®
Graphite
Article number
White
Article number + W
Additional versions of this
luminaire and other inspiring
lighting ideas can be found on
our website using the following
web code:
Page 43
The half beam angle β describes the size of the light cone with which an object or surface is actually illuminated. Luminaires
with wider half beam angles should be chosen for short lighting distances, a focused light is recommended for larger distances.
Symmetrical narrow beam
β
Controllable
A
B
24 381 K3
7.0 W
790 lm
16°
DALI
110
70
24 382 K3
14.0 W
1460 lm
16°
DALI
110
70
Symmetrical wide beam
β
Controllable
A
B
24 383 K3
7.0 W
780 lm
32°
DALI
110
70
24 384 K3
14.0 W
1380 lm
32°
DALI
110
70
Symmetrical very wide beam
β
Controllable
A
B
24 385 K3
7.0 W
785 lm
58°
DALI
110
70
24 386 K3
14.0 W
1385 lm
58°
DALI
110
70
24 628 K3
7.0 W
690 lm
79°
DALI
110
70
24 629 K3
14.0 W
1230 lm
79°
DALI
110
70
Asymmetrical
β
Controllable
A
B
24 369 K3
10.0 W
720 lm
51°/57°
DALI
110
70
Please enter this reference
number into the search field
on our website.
33
