L
B
A
STUDIO LINE
BEGA system pendant luminaires
The light of the cylindrical system pendant luminaires
is bundled using a reflector, and then precisely emitted
directly downward into the room. Their clear, modern
design makes them particularly suited for streamlined,
geometrically inspired design.
Like all luminaires in the STUDIO LINE series, the
cylindrical models also allow for the option to choose
between different inner colours. The direct portion of
the light emits directly downward, while the remaining
luminous energy is reflected onto the metallic interior
surface and produces a gentle light mood depending on
the colour.
Each system pendant luminaire will require its specific
installation component depending on the installation
situation. By using a smart canopy, the luminaires can
be integrated into BEGA Smart and controlled wirelessly.
You will find the right installation components from the
article numbers of the system pendant luminaires on our
website.
Material
Metal housing
Chrome trim ring
Silicone diffusing lens
Pure anodised aluminium reflector
Cable pendant in luminaire colour
BEGA Thermal Management®
protects the luminaires from overheating
due to excessive ambient temperatures
Controllable
on/off · DALI
*BEGA Smart (in combination
with type AS or CS canopy)
Lamp
BEGA LED module
LED colour temperature
3000 K
Page 191
Inside colour
Matt brass
Article number + .4
Matt aluminium
Article number + .2
Matt copper
Article number + .6
Outside colour
Velvet white
Velvet black
Inside colour matt aluminium
Velvet white
Velvet black
β
Controllable
A
B
L
51 027.2 K3
51 026.2 K3
5.6 W
380 lm
22°
on/off*
90
90
2000
50 990.2 K3
50 987.2 K3
9.2 W
915 lm
24°
on/off
120
115
2000
50 991.2 K3
50 988.2 K3
13.7 W
1215 lm
32°
DALI*
135
125
3000
50 992.2 K3
50 989.2 K3
19.0 W
1860 lm
35°
DALI*
180
150
3000
Inside colour matt brass
Velvet white
Velvet black
β
Controllable
A
B
L
51 027.4 K3
51 026.4 K3
5.6 W
345 lm
23°
on/off*
90
90
2000
50 990.4 K3
50 987.4 K3
9.2 W
860 lm
34°
on/off
120
115
2000
50 991.4 K3
50 988.4 K3
13.7 W
1125 lm
33°
DALI*
135
125
3000
50 992.4 K3
50 989.4 K3
19.0 W
1730 lm
40°
DALI*
180
150
3000
Inside colour matt copper
Velvet white
Velvet black
β
Controllable
A
B
L
51 027.6 K3
51 026.6 K3
5.6 W
325 lm
23°
on/off*
90
90
2000
50 990.6 K3
50 987.6 K3
9.2 W
805 lm
33°
on/off
120
115
2000
50 991.6 K3
50 988.6 K3
13.7 W
1095 lm
43°
DALI*
135
125
3000
50 992.6 K3
50 989.6 K3
19.0 W
1625 lm
43°
DALI*
180
150
3000
Select the appropriate canopy for each individual system pendant luminaire
to match the existing installation situation: bega.com/system-pendants
β = Half beam angle
259
