IP20
Length
1184 mm
2368 mm
Code
AE400. 01/04
AE410. 01/04
AE420. 01/04
AE430. 01/04
Optic
2x4 optics
3x4 optics
4x4 optics
6x4 optics
45
85
Beam
S 20°
F 36°
XF 52°
S 20°
F 36°
XF 52°
S 20°
F 36°
XF 52°
S 20°
F 36°
XF 52°
Code
BH120. 01/04/05
BH121. 01/04/05
BH124. 01/04/05
BH125. 01/04/05
BH128. 01/04/05
BH129. 01/04/05
BH080. 01/04/05
BH081. 01/04/05
BH084. 01/04/05
BH085. 01/04/05
BH088. 01/04/05
BH089. 01/04/05
BH140. 01/04/05
BH141. 01/04/05
BH144. 01/04/05
BH145. 01/04/05
BH148. 01/04/05
BH149. 01/04/05
BH100. 01/04/05
BH101. 01/04/05
BH104. 01/04/05
BH105. 01/04/05
BH108. 01/04/05
BH109. 01/04/05
Code
BH122. 01/04/05
BH123. 01/04/05
BH126. 01/04/05
BH127. 01/04/05
BH130. 01/04/05
BH131. 01/04/05
BH082. 01/04/05
BH083. 01/04/05
BH086. 01/04/05
BH087. 01/04/05
BH090. 01/04/05
BH091. 01/04/05
BH142. 01/04/05
BH143. 01/04/05
BH146. 01/04/05
BH147. 01/04/05
BH150. 01/04/05
BH151. 01/04/05
BH102. 01/04/05
BH103. 01/04/05
BH106. 01/04/05
BH107. 01/04/05
BH110. 01/04/05
BH111. 01/04/05
CCT
3000 K
4000 K
3000 K
4000 K
3000 K
4000 K
3000 K
4000 K
3000 K
4000 K
3000 K
4000 K
3000 K
4000 K
3000 K
4000 K
3000 K
4000 K
3000 K
4000 K
3000 K
4000 K
3000 K
4000 K
Length
1184 mm
2368 mm
Optic
2x4 optics
3x4 optics
4x4 optics
6x4 optics
Code
BH350. 01/04/05
F
S
XF
Code
AF06000
Silver
05
Black
04
White
01
MacAdam 2SDCM
L90 (20k) 118000h
CRI >90
W
27 W direct
26 W indirect
38 W direct
26 W indirect
54 W direct
50 W indirect
70 W direct DALI
75 W direct Undimmable
50 W indirect
Flux1
1648 lm direct
3075 lm indirect
1764 lm direct
3075 lm indirect
1542 lm direct
3075 lm indirect
1650 lm direct
3075 lm indirect
1597 lm direct
3075 lm indirect
1709 lm direct
3075 lm indirect
2473 lm direct
3075 lm indirect
2646 lm direct
3075 lm indirect
2314 lm direct
3075 lm indirect
2476 lm direct
3075 lm indirect
2396 lm direct
3075 lm indirect
2564 lm direct
3075 lm indirect
3297 lm direct
6150 lm indirect
3528 lm direct
6150 lm indirect
3085 lm direct
6150 lm indirect
3301 lm direct
6150 lm indirect
3195 lm direct
6150 lm indirect
3419 lm direct
6150 lm indirect
4945 lm direct
6150 lm indirect
5292 lm direct
6150 lm indirect
4627 lm direct
6150 lm indirect
4952 lm direct
6150 lm indirect
4792 lm direct
6150 lm indirect
5128 lm direct
6150 lm indirect
Dimmable DALI**
Undimmable
Code
BH440. 01/04
303
57
75
57
75
303
Code
AT09500
BH164. 01/04/05
AT10400
AT10500
AT10500APP
Louvers
End caps kit 2x
Undimmable Feeding kit including 2 suspension
cables (3 poles) 2000h mm
Dimmable or APP Feeding kit
including 2 suspension cables (5 poles) 2000h mm
Mechanical joint including 1 suspension cable
Accessories suspension
Direct and Indirect emission
Angle elements (not lit)
90° suspension corner
(on same plane)
L=57x57 mm
Optional accessories
Louvers supplied separately.
Sharping wall grazer lens Kit (4pcs)
26°x70° elliptical lenses kit. It has to be
used on top of S 20° reflectors to get
an elliptical beam (greater axis along
the module length). It contains 4 lenses.
Covers (not lit)
90° corner covers
L=57x57 mm
APP interface supplied separately.
The APP driver can not be controlled by DALI
dimming system and viceversa.
A . 3 9 S H A R P I N G E M I S S I O N - S U S P E N S I O N
** Uses 2 DALI addresses
1 Direct luminous flux: measured using white louvres.
With black louvres -10% output flux.
