Undimmable
Dimmable DALI
Code
AQ453. 01/04
15/18/20
AQ451. 01/04
15/18/20
AQ494. 01/04
15/18/20
AQ49500
Code
AQ174. 01/04
AQ171. 01/04
AQ176. 01/04
AQ18000
AQ18100
Code
AQ154. 01/04
AQ154. 01/04 APP
AQ161. 01/04
AQ161. 01/04 APP
AQ175. 01/04
AQ175. 01/04 APP
DV1061
AQ16000
AQ16000APP
Code
AQ260. 01/04
AQ261. 01/04
AQ015. 01/04
AQ014. 01/04
AQ262. 01/04
AQ911. 01/04
AQ921. 01/04
AQ920. 01/04
Undimmable
Dimmable DALI / APP
Insulating spacer
(1 pcs) between modules
powered by different
power supplies
End caps
(2 pcs) including
2 suspension cables 200H
Transition cap
track - diffusing
track - sharping
diffusing - sharping
Auxiliary suspension
cable
(1 pcs) to be used for
S-configuration
Accessories
Power supply
240W Recessed power
supply kit
(cable length 2,2 m)
230VAC-48VDC
IP20
396x195x112H
240W Power supply kit
(cable length 2,2 m)
230VAC-48VDC
IP20
400x110x49H
150W Power supply kit
(cable length 2,2 m)
230VAC-48VDC
IP20
400x110x49H
240W Bare power supply + plug
ON-OFF 230VAC-48VDC
IP20
(1 feed connector)
(for dimmable version to be
combined with “DALI-Selv
interface”) 244x68x38H
150W Bare power supply + plug
ON-OFF 230VAC-48VDC
IP20
(1 feed connector)
(for dimmable version to be
combined with “DALI-Selv
interface”) 244x68x38H
240W Recessed power supply kit
(cable length 2,2 m)
230VAC-48VDC
IP20
396x195x112H
240W Power supply kit
(cable length 2,2 m)
230VAC-48VDC
IP20
400x110x49H
150W Power supply kit
(cable length 2,2 m)
230VAC-48VDC
IP20
400x110x49H
DALI to DALI-Selv Interface
103x67x21H
240W Remote box power
supply kit (2 connectors)
230VAC-48VDC
IP20
(2 feed connectors)
313x243x57,5H
Louver for linear modules
Sharping kit L=1176mm
(2 louvers - 1 intermediate cover -
2 end covers)
Sharping kit L=2352mm
(4 louvers - 3 intermediate cover -
2 end covers)
X joint
(1 louver + 4 cover)
T joint
(1 louver + 3 cover)
90° angle cover
(2 pcs)
Louver for curved modules
R=561mm/R=750mm
R=561mm 60° order 1 pc
90° order 1 pc
R=750mm 45° order 1 pc
90° order 2 pcs
Flexible cover 2m
Flexible cover 10m
Each linear, angle and curved modules are provided with mechani-
cal and electrical joints, and installation accessories.
1 suspension cable is also included.
End caps have to be ordered separately.
Sharping kit (louvers and covers) has to be ordered separately.
The APP driver can not be controlled by DALI dimming system and
viceversa.
The white power kit is supplied with a white cable, while the black
power kit is supplied with a black cable.
