Grey-white
Ral 9002
IP65
IK06
MacAdam 3SDCM
CRI =80
45
110
52
117
81
45
110
52
117
81
Code
T4522030A
Code
T4521030
W
Weight
Flux
CCT
9 W
0,46 kg
60 lm
3000K
W
Weight
Beam
Flux
3 W
0,47 kg
15 lm
A N TA R K T I K Ó S
Code
NL19035
DV3003
DV1003
DV1042
Driver
Vac
Lmm Wmm Hmm IP
n°device in series
cc 10W
700mA 220-240
75
38
25
20 1max
Undimmable
cc 14W
700mA 220-240
79
38
25
67 1-2max
Undimmable
cc 25W
900mA 220-240
164 38
25
20 1-2max
DALI/PUSH dimmable
cc 38W
900mA 220-240
185 35
33
67 1-4max
DALI/PUSH dimmable
Driver
Iout Vin
Vout
Lmm
Wmm
Hmm
IP
n°device in series
25 W
100-277 Vac 12Vdc
148
40
32
67
max 5
40 W
100-277 Vac 12Vdc
163
43
32
67
max 8
96 W
100-277 Vac 12Vdc
140
63
32
67
max 20
150 W
100-277 Vac 12Vdc
228
68
39
67
max 30
DIMMER DMX 350mA 12-24Vdc
88
54
25
20
max 1
DIMMER DALI 350mA 12-24 Vdc
88
54
25
20
max 1
Code
DV1055
DV1056
DV1057
DV1043
DV1059
DV1052
12 Vdc
DMX
DMX
DIMMER
DMX
DIMMER
DMX
DIMMER
DMX
DIMMER
Antarktikós
1
Antarktikós
2
Antarktikós
3
Antarktikós
n°
CV DRIVER
12 Vdc
DALI
DALI
DIMMER
DALI
DIMMER
DALI
DIMMER
DALI
DIMMER
Antarktikós
1
Antarktikós
2
Antarktikós
3
Antarktikós
n°
CV DRIVER
12 Vdc
DMX
DMX
DIMMER
DMX
DIMMER
DMX
DIMMER
DMX
DIMMER
Antarktikós
1
Antarktikós
2
Antarktikós
3
Antarktikós
n°
CV DRIVER
12 Vdc
DALI
DALI
DIMMER
DALI
DIMMER
DALI
DIMMER
DALI
DIMMER
Antarktikós
1
Antarktikós
2
Antarktikós
3
Antarktikós
n°
CV DRIVER
Notes:
It is necessary to use 1 Dimmer for each Antarktikos RGB as indicated in the scheme.
Use DMX suitable twisted pair cables with an impedance of 120Ω and a low capacitance.
Max. of 32 standard devices connected over a max. cable length of 300m wired in a multi-drop bus topology commonly called “daisy chain”.
Terminate the last driver with an impedance of 120Ω (120Ω resistor joining pins + and -).
After 32 unit loads a repeater/booster should be used.
Use DMX Splitters for larger installations or to simplify wiring. The output of a DMX splitter is considered a new DMX line, with the same rules applying.
ANTARKTIKÓS WHITE EMISSION
ANTARKTIKÓS RGB EMISSION
Driver 700/900 mA SELV supplied separately.
Vf=9V reported values are subject to a tolerance +/-10%.
Driver 12Vdc Power Supply and 350mA constant current DIMMER supplied separately.
