Photorealistic rendering.
ON/OFF (A)
4000K (-840 = CRI 80 / CCT 4000
21
3000K (-830 = CRI 80 / CCT 3000)
16
145
EXTERIOR
LUMINAIRE
• Die-cast aluminium body and trim (EN 47100).
• Double layer polyester powder paint resistant to corrosion and salt spray fog.
• AISI 316 stainless steel external screws.
• Lenses made of optical grade PMMA with free-form technology. Special surface finish to minimize
chromatic aberrations and ensure optimal color mixing in dynamic white or colored light applications.
• Screen made of 5mm thermal-shock resistant tempered glass.
• High quality LED sources mounted on metal-based modules for better thermal load management and
characterized according to LM-80 methodology for longevity and IES TM-30 for colorimetric characteristics.
High color consistency <3SDCM, for guaranteed long life, in compliance with installation requirements, for
more than 60,000 hours with parameters L80B20.
• Appliance built in compliance with EN 60598-1 and EN 60598-2-2 standards, complete with CE marking in
compliance with EU directives.
INSTALLATION
• Recessed installation in a special outer casing (included in the package) in glass-fibre reinforced plastic
material or in AISI 316L stainless steel. It is possible to pre-order the outer boxes to prepare the system.
• PG11 tecnopolymer cable gland.
These fittings are suitable for the modern control systems. For the various possibilities, please see section
“Controlling the light”.
STANDARD PRODUCT
Wiring
CCT
Colour
Aluminium (similar to RAL 9006)
AVAILABLE OPTIONS
Grey (similar to RAL 7024)
