4
ECO0
ECO1
ECO2
ECO1 | ECO2
ECO is the new Range of floodlights for large areas, architectural applications (direct and indirect light) and urban
lighting in public and residential settings. High performances, extreme reliability and energy efficiency in a product
manufactured with sustainable raw materials such as aluminium, glass and steel.
The linear and compact design is the result of a careful design aimed at garanteeing a pleasant aesthetic product
and the highest heat dissipation.
ECO Range is available in 3 dimensions, ECO0, ECO1, ECO2 as:
- Floodlight (with bracket attachment in steel);
- Urban for post top applications (with adjustable adapter for Ø 60mm pole or reduction).
The new Range of floodlights for large areas,
architectural and urban lighting.
MAIN FEATURES
• Die-cast aluminium body (EN 47100).
• Polyester powder paint resistant to corrosion and salt spray fog.
• Silicone rubber gaskets.
• AISI 316 stainless steel external screws.
• Driver protected against voltage surges.
• Floodlight: anodised aluminium reflector specular anti-glare or
optical polymer lenses.
• Urban (post top): PMMA lenses for LEDs.
• Screen made of 4mm thermal-shock resistant tempered glass.
• High quality LED sources characterized according to IES TM-30,
with high color consistency <3SDCM and long useful life >80000
hours at L80.
• EN 60598-2-5 or EN 60598-2-3 (according to application).
INSTALLATION (Floodlight)
• Galvanized and painted steel bracket.
• Tecnopolymer M20 cable gland.
• Supplied with power cable (0.5m).
INSTALLATION (Urban - post top)
• Post top installation (Ø60mm reduction).
• Possibility of orientation:
Post top: -5° ÷ +30°; Reach: -30° ÷ +30°
• Tecnopolymer M20 cable gland with anti-condensation valve.
• Supplied with power cable with IP66 socket-plug connector with
clamping ring for cables from 9 up to 12mm.
NOTE: Also available with CCT: 3000K (-830)
Also available with wiring: DALI (B) upon request
Also available in black 12 (-12) and dark grey 16 (-16)
ECO0, ECO1, ECO2
Available in Performance and Professional version
with several optics and wattages.
Floodlights
Post top
ECO1
ECO2
ECO0
PROFESSIONAL FLOODLIGHTS ECO / EQOS
A selection of the available versions
A selection of the available versions
A selection of the available versions
URBAN LIGHTING
FLOODLIGHT
FLOODLIGHT
FLOODLIGHT
ECO [Range]
(20W up to 99W)
(50W up to 147W)
(106W up to 190W)
(106W up to 190W)
