67
66
LIGHT SOURCE
FUENTE DE LUZ
Light source built in
Fuente de luz incluída
230 V | 50 Hz
17W | 2700K | 1645lm built in
upon request 3000K 1776lm
Dimmer: PHASE CUT
100~277 V |
60 Hz
17W | 2700K | 1645lm built in
upon request 3000K 1776lm
Dimmer: PHASE CONTROL & 0-10V
(only 120Vac TRIAC Dimmers)
2,3 kg | 5,1 lb
PACKAGING
EMBALAJE
60x60x33 cm | 23,6x23,6x13”
4,7 kg | 10,4 lb
Ura
Arturo Álvarez, 2017
MATERIALS
MATERIALES
Painted stainless steel
Acero inoxidable pintado
Stainless steel
Acero inoxidable
FINISHES
ACABADOS
White · Blanco
BL
Beige · Beige
BE
Grey · Gris
G
Taupe · Topo
T
Black · Negro
N
Custom · Personalizado
CC
CABLE
Transparent or black
Transparente o negro
Standard: 150 cm | 59,1”
120 V: 200 cm | 78,7”
Lenght/Largo customizable
CANOPY
FLORÓN
Steel gloss nickel- plated
Acero niquel-satinado
230V: Ø8cm | 3,1”
120V: Ø12cm | 4,7”
CANOPY
FLORÓN
Steel gloss nickel- plated
Acero niquel-satinado
230V: Ø12cm | 4,7”
120V: Ø12cm | 4,7”
DIFFUSER
DIFUSOR
Bottom diffuser
Difusor inferior
LIGHT SOURCE
FUENTE DE LUZ
Recommended bulbs
Bombillas recomendadas
230 V | 50 Hz
E27 LED Vintage-
Max. 1x12 W
120 V | 60 Hz
E26 LED - Max. 1x12 W
NET WEIGHT
PESO NETO
1,8 kg | 4 lb
PACKAGING
EMBALAJE
60x60x33 cm | 23,6x23,6x13”
4,2 kg | 9,2 lb
LIGHT SOURCE
FUENTE DE LUZ
Recommended bulbs
Bombillas recomendadas
230 V | 50 Hz
E27 LED Vintage-
Max. 1x12 W
120 V | 60 Hz
E26 LED - Max. 1x12 W
NET WEIGHT
PESO NETO
1,1 kg | 2,4 lb
PACKAGING
EMBALAJE
46x24x26 cm | 18,1x9,4x10,2”
1,6 kg | 3,5 lb
UR104
UR104-LD
UR204
UR204-LD
Ø 50 cm · 19,7”
Ø 50 cm · 19,7”
Ø 20 cm · 7,9”
Ø 20 cm · 7,9”
26 cm · 10,2”
26 cm · 10,2”
43 cm · 16,9”
43 cm · 16,9”
A
G
D
NET WEIGHT
PESO NETO
LIGHT SOURCE
FUENTE DE LUZ
Light source built in
Fuente de luz incluída
230 V | 50 Hz
17W | 2700K | 1645lm built in
upon request 3000K 1776lm
Dimmer: PHASE CUT
100~277 V |
60 Hz
17W | 2700K | 1645lm built in
upon request 3000K 1776lm
Dimmer: PHASE CONTROL & 0-10V
(only 120Vac TRIAC Dimmers)
1,7 kg | 3,7 lb
PACKAGING
EMBALAJE
46x24x26 cm | 18,1x9,4x10,2”
2,1 kg | 4,6 lb
A
G
D
NET WEIGHT
PESO NETO
LIGHT SOURCE
FUENTE DE LUZ
Recommended bulbs
Bombillas recomendadas
230 V | 50 Hz
E27 LED Vintage-
Max. 1x12 W
120 V | 60 Hz
E26 LED - Max. 1x12 W
NET WEIGHT
PESO NETO
1,3 kg | 2,9 lb
PACKAGING
EMBALAJE
36x36x31 cm | 14,2x14,2x12,2”
1,6 kg | 3,5 lb
LIGHT SOURCE
FUENTE DE LUZ
Light source built in
Fuente de luz incluída
230 V | 50 Hz
17W | 2700K | 1645lm built in
upon request 3000K 1776lm
Dimmer: PHASE CUT
upon request DALI/ Switch DIM
100~277 V |
60 Hz
17W | 2700K | 1645lm built in
upon request 3000K 1776lm
Dimmer: PHASE CONTROL & 0-10V
(only 120Vac TRIAC Dimmers)
NET WEIGHT
PESO NETO
1,8 kg | 4 lb
PACKAGING
EMBALAJE
36x36x31 cm | 14,2x14,2x12,2”
2 kg | 4,4 lb
LIGHT SOURCE
FUENTE DE LUZ
Light source built in
Fuente de luz incluída
230 V | 50 Hz
4 W | 2700K | 350lm built in
upon request 3000K 370lm
Dimmer: PHASE CUT
100~277 V |
60 Hz
4 W | 2700K | 350lm built in
upon request 3000K 370lm
Dimmer: PHASE CONTROL
NET WEIGHT
PESO NETO
1,1 kg | 2,4 lb
PACKAGING
EMBALAJE
25x25x28 cm | 9,8x9,8x11”
1,6 kg | 3,5 lb
Veiga
Isaac Piñeiro, 2025
FINISHES
ACABADOS
White · Blanco
B
Cream · Crema
CM
Grey · Gris
Amethyst · Amatista
CABLE
Black · Negro
Standard: 150 cm | 59,1”
120 V: 200 cm | 78,7”
Lenght/Largo customizable
CANOPY
FLORÓN
Black · Negro
230V: Ø8cm | 3,1”
120V: Ø12cm | 4,7”
UR304
URA304-LD
VA04
Ø 18 cm · 7”
12,6 cm · 5”
Ø 33 cm · 13”
Ø 33 cm · 13”
26 cm · 10,2”
26 cm · 10,2”
A
G
D
A
G
D
Colored glass
Vidrio soplado
MATERIALS
MATERIALES
G
AM
